Image preview - the first page of the document
>> Download SONY KV-25X5_FE1 documenatation <<Text preview - extract from the document SELF-DIAGNOSTIC FUNCTION
SERVICE MANUAL FE-1 CHASSIS
MODEL COMMANDER DEST CHASSIS NO. MODEL COMMANDER DEST CHASSIS NO.
KV-25X5A RM-883 Italian SCC-Q06E-A
KV-25X5K RM-883 OIRT SCC-Q03E-A
KV-25X5B RM-883 French SCC-Q02E-A KV-25X5L RM-883 Irish SCC-Q07B-A
KV-25X5D RM-883 AEP SCC-Q04E-A KV-25X5R RM-883 OIRT SCC-Q03F-A
KV-25X5E RM-883 Spanish SCC-Q05E-A
KV-25X5U RM-883 UK SCC-Q01D-A
/
MENU
PROGR
RM-883
TRINITRON
