Image preview - the first page of the document



>> Download Sony_KV32FV15_Part1 documenatation <<

Text preview - extract from the document

                               KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K
                               34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K




SERVICE MANUAL                                     AA-2W CHASSIS
    MODEL              DEST.         COMMANDER               CHASSIS NO.

   KV-32FS10           U.S.           RM-Y168                SCC-S32B-A
   KV-32FS10           CND            RM-Y168                SCC-S33B-A
   KV-36FS10           U.S.           RM-Y168                SCC-S32C-A
   KV-36FS10           CND            RM-Y168                SCC-S33C-A
   KV-32FV15           U.S.           RM-Y171                SCC-S32D-A
   KV-32FV15           CND            RM-Y171                SCC-S33D-A
   KV-34FV10           E              RM-Y168                SCC-S34E-A
   KV-34FV15           E              RM-Y171                SCC-S34F-A
   KV-34FV15C          E              RM-Y171                SCC-S34G-A
   KV-34FV15K          KOREA          RM-Y149A               SCC-S31B-A
   KV-34FV15T          TAIWAN         RM-Y171                SCC-S36A-A
   KV-36FV15           U.S.           RM-Y171                SCC-S32G-A
   KV-36FV15           CND            RM-Y171                SCC-S33G-A
   KV-38FV15K          KOREA          RM-Y149A               SCC-S31C-A
   KV-34FX250C         E              RM-Y170                SCC-S34H-A
   KV-38FX250          E              RM-Y170                SCC-S34M-A
   KV-38FX250C         E              RM-Y170                SCC-S34J-A
   KV-38FX250T         TAIWAN         RM-Y170                SCC-S36B-A
   KV-32XBR250         U.S.           RM-Y170                SCC-S32E-A
   KV-32XBR250         CND            RM-Y170                SCC-S33E-A
   KV-36XBR250         U.S.           RM-Y170                SCC-S32F-A
   KV-36XBR250         CND            RM-Y170                SCC-S33F-A




                                                                  RM-Y170




                 KV-36XBR250
                                                   TRINITRON
