SONY XR-C440E_XR-C450E_XR-C440_XR-C450


>> Download SONY XR-C440E_XR-C450E_XR-C440_XR-C450 documenatation <<

Text preview - extract from the document
                                                  XR-C440/C450
SERVICE MANUAL                                                                                                     US Model
                                                                                                              Canadian Model
                                                                                                                                       XR-C450
Ver 1.1 2001.08
                                                                                                                                E Model
                                                                                                                                XR-C440/C450




                                                                 Photo: XR-C450

Refer to RM-X2S/X3S SERVICE MANUAL (9-960-039-)
issued previously for information of remote commander
(RM-X2S) supplied with XR-C440.



Dolby noise reduction manufactured under license
                                                                                   Model Name Using Similar Mechanism                 NEW
from Dolby Laboratories Licensing Corporation.
"DOLBY" and the double-D symbol a are trademarks                                   Tape Transport Mechanism Type                    MG-25C-136
of Dolby Laboratories Licensing Corporation.
                                                            SPECIFICATIONS

AUDIO POWER SPECIFICATIONS (US model)
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
12 watts per channel minimum continuous average power into 4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more than 1% total
harmonic distortion.

Cassette player section                                                    Antenna terminal        External antenna connector
Tape track            4-track 2-channel stereo                             Intermediate frequency 10.7 MHz
Wow and flutter       0.08% (WRMS)                                         Usable sensitivity      8 dBf
Frequency response    30
