Sony DVD Code C-81 1


>> Download Sony DVD Code C-81 1 documenatation <<

Text preview - extract from the document
                                                            Technical Bulletin
 Date            Ref. No.      Model                                                                  HA
 28.06.02        AU00302R      HCD-C700, HCD-S500, HCD-S800

 Subject                                                                                              IRIS

 No Operation in DVD Mode [REVISION]                                                                  C11A


SYMPTOM
No operation in the DVD mode. In some cases "C-81" appears on the display.

CAUSE
Q002 on the DVD board may be defective.

SOLUTION
Apply the following changes on the DVD Board.

    Remove Q002 "2SA1213Y" (8-729-101-07).
    Replace R011 "Chip 1k" (1-218-953-11) with "Chip 470 Ohm" (1-218-949-11).
    Solder the lead wires of the new part "Housing (Q002) Assy" (X-4954-896-1) to the locations shown. Be
    careful not to touch any other pattern.




            Flag     Symptom        Part        Ref.    Section    PCB       Defect   Repair   Qty.
                       code        number                code                 code     code
             1        C11A      X-4954-896-1   Q002      PSU      Digital      R         I      1
             1        C11A      1-218-949-11   R011      PSU      Digital      R         I      1



                                        Sony Service Centre (Europe) N.V.
                                         European Service Engineering
                                               Technologielaan 7
                                              B - 1840 Londerzeel
                                                                                                        1/2
2/2                                             AU00302R
  Screw the part "Housing (Q002) Assy" to the Amp Board as indicated. Be careful not to touch any part on the
  DVD Board or the Power Board.




APPLICABLE SERIAL NUMBERS
                                    HCD-S500 (CEK)      up to 6629280
                                    HCD-S500 (CEL)      up to 5599719
                                    HCD-S800 (CEK)      up to 6816006
                                    HCD-S800 (CEL)      up to 5759018
