Image preview - the first page of the document
Sony HCD-ED2


>> Download Sony HCD-ED2 documenatation <<

Text preview - extract from the document
                                                             HCD-ED2
  SERVICE MANUAL                                                                         US Model
                                                                                  Canadian Model
                                                                                       AEP Model
                                                                                         UK Model
                                                                                           E Model
                                                                                  Australian Model



 HCD-ED2 is the tuner, deck, CD and
 amplifier section in CMT-ED2.



                                                  Model Name Using Similar Mechanism NEW

                                        CD        Mechanism Type                    CDM-61
                                      SECTION     Base Unit Type                    KSM-331AAN/K1NP
                                                  Optical Pick-up Type              KSS-331A (RP)
                                                  Model Name Using Similar Mechanism NEW
                                      TAPE DECK
                                       SECTION
                                                  Tape Transport Mechanism Type     CMAL1Z025A


                                         SPECIFICATIONS




                                                                                   -- Continued on next page --



                                                     COMPACT DISC DECK RECEIVER

MICROFILM


                                                                                                             1
                                                      Laser component in this product is capable of emitting radiation
                                                      exceeding the limit for Class 1.


                                                                                         This appliance is classified as
                                                                                         a CLASS 1 LASER product.
                                                                                         The CLASS 1 LASER PROD-
                                                                                         UCT MARKING is located on
                                                                                         the rear exterior.

                                                                                                        This caution
                                                                                                        label is located
                                                                                                        inside the unit.




                                                      CAUTION
                                                      Use of controls or adjustments or performance of procedures
                                                      other than those specified herein may result in hazardous ra-
                                                      diation exposure.

                                                     Notes on chip component replacement
