Image preview - the first page of the document
Sony RDR-HX715


>> Download Sony RDR-HX715 documenatation <<

Text preview - extract from the document
                                                    RDR-HX715                                    RMT-D218A

SERVICE MANUAL                                                                           US Model
                                                                                    Canadian Model




                                          SPECIFICATIONS
    System                                          COMPONENT VIDEO OUT (Y, PB, PR):
    Laser: Semiconductor laser                        Phono jack/Y: 1.0 Vp-p/PB, PR:
    Channel coverage:                                 interlace*=0.648 Vp-p, progressive or
       NTSC                                           interlace**=0.7 Vp-p
       VHF: 2 to 13/UHF: 14 to 69/CATV: A-8 to      COMPONENT VIDEO IN (Y, PB, PR):
       A-1, A to W, W+1 to W+84                       Phono jack/Y: 1.0 Vp-p/PB, PR:
    Video reception: Frequency synthesizer system     interlace*=0.648 Vp-p, progressive or
    Audio reception: Split carrier system             interlace**=0.7 Vp-p
    Antenna: 75-ohm antenna terminal for VHF/       * "Y/Pb/Pr Out Black Level" is "On"
       UHF                                          ** "Y/Pb/Pr Out Black Level" is "Off"
    Timer: Clock: Quartz locked/Timer indication:   SET TOP BOX CONTROL:
       12-hour cycle (digital)/Power back-up           Mini jack
       duration: 1 hour                             HDMI OUT:
    Video recording format: MPEG Video                 Type A (19-pin)
    Audio recording format/applicable bit
       rate: Dolby Digital 2 ch/256 kbps            General
                                                    Power requirements: 120 V AC, 60 Hz
    Inputs and outputs                              Power consumption: 57 W
    LINE OUT 1/2                                    Dimensions (approx.): 430
