Image preview - the first page of the document
WX-4500X


>> Download WX-4500X documenatation <<

Text preview - extract from the document
                                                                      WX-4500X
SERVICE MANUAL                                                                                                              US Model
Ver 1.1 2002. 10




Dolby noise reduction manufactured under license from Dolby Labo-                 Model Name Using Similar Mechanism             NEW
ratories Licensing Corporation.                                       CD                                                         MG-318RW/
"DOLBY" and the double-D symbol ; are trademarks of Dolby                         CD Drive Mechanism Type
                                                                      Section                                                    A-153
Laboratories Licensing Corporation.                                               Optical Pick-up Name                           RAF0143A
                                                                      TC          Model Name Using Similar Mechanism             WX-C55
                                                                      Section     Tape Transport Mechanism Type                  MG-25E-136



                                                              SPECIFICATIONS

AUDIO POWER SPECIFICATIONS                                            Tuner section
POWER OUTPUT AND TOTAL HARMONIC DISTORTION                            FM
23 watts per channel minimum continuous average power into            Tuning range             FM tuning interval:
4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more                                    50 kHz/200 kHz switchable
                                                                                               87.5
