Image preview - the first page of the document



>> Download TVP0172 documenatation <<

Text preview - extract from the document

                                     TV Products                                                   CSV-1
                                     Service Bulletin
                                     Sony Service Company - Technical Services
                                     A Division of Sony Electronics Inc.
                                     Sony Drive, Park Ridge, New Jersey 07656


Model:      KV-27TS29/27TS32/27TS36                                          No.    172R2
            KV-27S10/27S15
            KV-27V10/27V15
            KV-27V55/27XBR37
            KV-32TS36/32TS46/32S10/32S15
            KV-32V15/32XBR37

Subject: Schematic diagram of the Pincushion circuit on the                  Date: May 1, 1995
            "D" Board is incorrect


Symptom:
  (**)           The schematic diagram of the Pincushion Output circuit is incorrect. It does not show
                 the Pin Output connected to the circuit. Please correct your service manual with the
                 information below.



Solution:        Q503, the Pincushion Output transistor, on the "D" Board, schematic grid location E-
                 15, should be connected from the collector of Q-503, to the junction of L-510 and C-
                 508, schematic grid location F-216




Reference: FPR-P2093                                                                             PRINTED IN USA
