Image preview - the first page of the document



>> Download TVP0243 documenatation <<

Text preview - extract from the document

                                     TV Products                                                    CSV-1
                                     Service Bulletin
                                      Sony Service Company - Technical Services
                                      A Division of Sony Electronics Inc.
                                      Sony Drive, Park Ridge, New Jersey 07656


Model:      KP-41EXR95/41EXR96                                                No.    243
            KP-46S55/46V15/46V16
            KP-46XBR15/46XBR25/46XBR35
            KP-53S55/53V15/53V16/
            KP-53XBR15/53XBR25/53XBR35
            KP-61V15/61XBR28/61XBR38

Subject: 8 Pin Extension Cable For The E1 Board                               Date: May 1, 1995
            Is Now Available


Symptom:
     (**)     The service manual did not provide the part number for the extension cable needed
              to connect E1-24 to A-24. This extension is used in conjunction with the 50 pin
              extension board as show in the Connector Cable section of the manual. KP-46V15
              page 43).

Solution:       Please add this extension cable part number to your Service manual.

                                Extension Cable                               Part Number
                   8 Pin to 8 Pin Extension Cable Connector                   T-998-571-51




Reference: FPR-P                                                                                  PRINTED IN USA
