Image preview - the first page of the document



>> Download TVP0252 documenatation <<

Text preview - extract from the document

                                TV Products                                                       CSV-1
                                Service Bulletin
                                 Sony Service Company - Technical Services
                                 A Division of Sony Electronics Inc.
                                 Sony Drive, Park Ridge, New Jersey 07656


Model: KP-41EXR96                                                        No.    252
         KP-46S55/46V15/46V16/46XBR35
         KP-53S55/53V15/53V16/53XBR35
         KP-61V15/61XBR38

Subject: Service Manual V-out Circuit Correction                         Date: June 15, 1995


Symptom:
  (**)         The polarity of C1740 is reversed on D board schematic drawing.

               The location of C1740 in schematic is Vertical output circuit near IC1707(VG-
               OUT).

Solution:      Please note correct polarity as shown below.




Reference: FPR-Q0804                                                                           PRINTED IN USA
