Image preview - the first page of the document



>> Download TVP0280 documenatation <<

Text preview - extract from the document

                                  TV Products                                                  CSV-1
                                  Service Bulletin
                                  Sony Service Company - Technical Services
                                  A Division of Sony Electronics Inc.
                                  Sony Drive, Park Ridge, New Jersey 07656


Model:      KV-27XBR45, KV-32XBR45, KV-32XBR85                                No.    280
Subject: Loss Of Adjustment Data                                              Date: January 31, 1996


Symptom:
 (133)         If the set should go out of adjustment the following procedure should be undertaken.



Solution:      Check to make sure the cable wires between the "HB" board, top of unit, and the "M"
               board are not touching the CRT. These wires should be held in the slots of the
               terminal posts located on the top of the bezel cabinet. If the wires can not be
               secured in the slot then electrical tape should be added to secure the wires to the
               bezel slots. Make sure the rest of the cable is properly dressed along the entire
               length between the two boards so as not to touch the CRT.

               Re adjust the unit using the Service Mode and write the data into memory.




Reference: TVA US 12/22/95                                                                   PRINTED IN USA
