                                  TV Products                                                      CSV-1
                                  Service Bulletin
                                   Sony Service Company - Technical Services
                                   A Division of Sony Electronics Inc.
                                   Sony Drive, Park Ridge, New Jersey 07656


Model:      KV-13VM20, KV-13VM21, KV-20VM20                                    No.      296
Subject: Q1801 replacement may cause unit to shut                              Date: March 11, 1996
         down


Symptom:
 (111)         Unit ticks momentary then shuts down.



Solution:      Q1801 (stand by regulator on the D board) was replaced during early production with
               a metal tap type transistor 2SD1135-C). Although this transistor is not connected to
               a heat sink it is mounted next to IC1801's heat sink. Because of it's closeness to the
               IC1801 heat sink the metal tap may touch the heat sink. If this should occur re-
               mount Q1801 and add a dab of RTV (7-322-065-19) between the transistor and heat
               sink.

                   REF                    FORMER                                        NEW
                             DESCRIPTION          PART NUMBER              DESCRIPTION    PART NUMBER

                  Q1801         2SD2092                       N/A           2SD1135-C         8-729-301-42




Reference: FPR-R0206                                                                             PRINTED IN USA
