Image preview - the first page of the document
>> Download TVP0227 documenatation <<
Text preview - extract from the document
TV Products CSV-1
Service Bulletin
Sony Service Company - Technical Services
A Division of Sony Electronics Inc.
Sony Drive, Park Ridge, New Jersey 07656
Model: KV-27XBR10/27XBR15/27XBR60 No. 227
KV-27XBR65
KV-32XBR10/32XBR15/32XBR65
KV-32XBR70
Subject: Service Manual ABL Circuit Correction Date: September 29, 1994
Symptom:
(**) The schematic drawing of the ABL circuit is incorrect. The location of the mistake
is in Grid location N-18 and 19. Resistor R367 is shown connected to diode
D515, located at K-24.
Solution: Diode D515 is connected to the junction of R332 and D301. The corrected
schematic is shown below:
Reference: FPR-P2736 PRINTED IN USA
Autoflagged - NO
PRINTED ON RECYCLED PAPER
