Image preview - the first page of the document
>> Download TVP0544 documenatation <<Text preview - extract from the documentS CONFIDENTIAL CSV-1
Sony Service Company
National Technical Services Service Bulletin
A Division of Sony Electronics Inc.
Park Ridge, New Jersey 07656 TV Products
Model: KD-34XBR2, KDP-57XBR2, KDP-65XBR2 No. 544
Subject: Remote control decimal point button does not Date: August 20, 2001
work with Sony combination DSS/DTV receiver
(like SAT-HD100).
Symptom:
(1150) The customer complains that the decimal point button on the remote control supplied
with the set has no effect when using the remote control to direct tune a channel on a
Sony combination DSS/DTV receiver (like the SAT-HD100).
Solution: If the customer complains of this symptom, replace the remote control with a special
one that has been programmed with the DSS/DTV receiver decimal point function.
You must order part number T-998-608-01. The special remote controls are
physically identical to the standard remote controls.
REF FORMER NEW
DESCRIPTION PART NUMBER DESCRIPTION PART NUMBER
- STANDARD 1-476-689-11 SPECIAL RM- T-998-608-01
RM-Y185 Y185 REMOTE
REMOTE CONTROL
CONTROL
Reference: PRINTED IN USA
