S CONFIDENTIAL CSV-1
Sony Service Company
National Technical Services Service Bulletin
A Division of Sony Electronics Inc.
Park Ridge, New Jersey 07656 TV Products
Model: KV-27S42, KV-27S46, KV-27S55 No. 560
Subject: Two different types of A/V switch IC203 Date: January 30, 2002
Symptom:
(118X) There are two different types of A/V switch used but the Service Manual only shows
the block diagram for the one type.
Solution: The service manual is only showing the Block diagram for IC203, which is the 32-pin
A/V switch MM1311AD. This IC is used for models KV-27S42 and KV-27S46, which
are not PIP models. The Block Diagram for the 42 pin MM1313 used in the
KV-27S66, which is the PIP model, is not shown. Below is the Block diagram for the
two A/V switches.
Reference: Display Eng. PRINTED IN USA
