Image preview - the first page of the document
TVP0513


>> Download TVP0513 documenatation <<

Text preview - extract from the document
S                                        CONFIDENTIAL                                                CSV-1
Sony Service Company
National Technical Services              Service Bulletin
A Division of Sony Electronics Inc.
Park Ridge, New Jersey 07656             TV Products

Model:          KP-41T15, KP-41T25, KP-41T35, KP-46C36                          No.      513R1
                KP-46S15, KP-46S17, KP-46S25, KP-46V25
                KP-46V35, KP-48S35, KP-48V45, KP-53S15
                KP-53S17, KP-53S25, KP-53S35, KP-53V25
                KP-53V35, KP-53V45, KP-53XBR45
                KP-53XBR4CT, KP-61S35, KP-61V25
                KP-61V35, KP-61V45, KP-61XBR48

Subject: CRT Replacement                                                        Date: August 21, 2001


Symptom:
 (161X)                Ground of replacement CRT may be different than the original. Heater resistor value
                       change may be required.



Solution:              When replacing the CRT the following changes may be necessary.



1.    When replacing the CRT the original may have used a braided wire across the CRT to ground the
      CRT and CRT Board. The replacement CRT uses a grounding wire that connects to a ground lug.
      This grounding lug wire should be packed in the replacement CRT box. See picture below.


                                                                                       See note on
                                                                                       last page


                                                                                                Ground wire P/N
                                                                                                1-900-235-84




                                                        Fig 1

Reference: CRT Group PJA                                                                          PRINTED IN USA
TV Products Service Bulletin No. 513R1


2.   Heater resistor value change.

When the CRT is replaced it is required to check the heater resistor value. This resistor value will
change depending on how many newer CRTs are used. It should be checked even if you are only
changing one CRT because one might have been replaced prior to your present repair. Failure to do so
may cause the CRT life span to be shortened.

In order to determine if the CRT heater resistor is the older value or not, check the color of the CRT
plastic pin base stem. (See Fig 1)

Black stem indicates an older CRT and the value of the heater resistor was not changed.

White stem indicates a newer CRT and the value of the heater resistor may require a different value.

3.   Procedure for replacing the heater resistor.
     1. After replacing the defective CRT, check the color of the CRT plastic pin base stem of all three
        CRTs. (See Fig 1)

     2. The value of the heater resistor, on the E or G Board depending on the model, will be
        determined by how many of the CRTs have a white stem base. Refer to the chart below.

     3. Check the heater resistor value in the set and confirm if it is the correct value as per the chart
        below. If not please replace the resistor with the correct value.



      Replace resistors for the heater circuit with the correct value resistors
specified by the number of the new heater CRTs as shown in the following chart.

                                          Part Number Chart

                       Description                           Part Number

                0.22 Ohm 1 Watt                        1-216-341-11

                0.47 Ohm 1 Watt                        1-216-345-11

                1.2 Ohm 3 Watt                         1-216-390-11

                1.5 Ohm 3 W                            1-216-391-11




        See the tables below to determine what value resistor change is required
        if necessary.
                                                       New Heater Resistor
                                               Quantity of new type CRTs (white stem base) in the set
                                                after defective CRTs are replaced
   Model      Chassis      Former Heater             One                   Two              Three       Board
                             Resistor
  KP-41T15     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-41T25     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-46S15     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-46S17     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-46S25     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-46V25     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-46V35     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-53S15     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-53S17     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-53S25     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-53V25     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP53V35      RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
 KP-53XBR45    RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
KP-53XBR4CT    RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-61V25     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
  KP-61V35     RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board
 KP-61XBR48    RA-1     1 Ohm 1/12 W (R835)   No need to replace     0.47 Ohm 1W         0.22 Ohm 1W    E Board




                                        Continue on next page
TV Products Service Bulletin No. 513R1


                                                                           New Heater Resistor
                                                                   Quantity of new type CRTs (white stem base) in the set
                                                                    after defective CRTs are replaced
       Model            Chassis         Former Heater                    One                   Two              Three                    Board
                                           Resistor
     KP-41T35             RA-2       1.8 Ohm 3 W (R569)          No need to replace         1.5 Ohm 3 W              1.2 Ohm 3W         G Board
                                     0.68 Ohm 3W (R540)          No need to replace       No need to replace        0.47 Ohm 3W
     KP-43C36             RA-2       1.8 Ohm 3 W (R569)          No need to replace         1.5 Ohm 3 W              1.2 Ohm 3W         G Board
                                     0.68 Ohm 3W (R540)          No need to replace       No need to replace        0.47 Ohm 3W
     KP48S35              RA-2       1.8 Ohm 3 W (R569)          No need to replace         1.5 Ohm 3 W              1.2 Ohm 3W         G Board
                                     0.68 Ohm 3W (R540)          No need to replace       No need to replace        0.47 Ohm 3W
     KP-48V45             RA-2       1.8 Ohm 3 W (R569)          No need to replace         1.5 Ohm 3 W              1.2 Ohm 3W         G Board
                                     0.68 Ohm 3W (R540)          No need to replace       No need to replace        0.47 Ohm 3W
     KP-53S35             RA-2       1.8 Ohm 3 W (R569)          No need to replace         1.5 Ohm 3 W              1.2 Ohm 3W         G Board
                                     0.68 Ohm 3W (R540)          No need to replace       No need to replace        0.47 Ohm 3W
     KP-53V45             RA-2       1.8 Ohm 3 W (R569)          No need to replace         1.5 Ohm 3 W              1.2 Ohm 3W         G Board
                                     0.68 Ohm 3W (R540)          No need to replace       No need to replace        0.47 Ohm 3W
     KP-61S35             RA-2       1.8 Ohm 3 W (R569)          No need to replace         1.5 Ohm 3 W              1.2 Ohm 3W         G Board
                                     0.68 Ohm 3W (R540)          No need to replace       No need to replace        0.47 Ohm 3W
     KP-61V45             RA-2       1.8 Ohm 3 W (R569)          No need to replace         1.5 Ohm 3 W              1.2 Ohm 3W         G Board
                                     0.68 Ohm 3W (R540)          No need to replace       No need to replace        0.47 Ohm 3W



Note: As of 4/24/01, PJ CRT will begin the use of colored stem caps in their process. The color of the stem cap will match the color of the CRT.
They will begin with red and green. White will continue to be used on the blue tubes until the supply is exhausted, at which time they will begin the
use of blue stem caps also, we expect this to be sometime in June 2001. Please see picture below.
There has been no material change, only a dye added for color. Engineering analysis of dimensions, arc testing, flame testing, and pin cap
adhesion show no change in performance from our current stem cap.

Please note, that depending upon shipments, you may continue to see white stem caps only for some time.
TV Products Service Bulletin No. 513R1
