S                                         CONFIDENTIAL                                                 CSV-1
Sony Service Company
National Technical Services               Service Bulletin
A Division of Sony Electronics Inc.
Park Ridge, New Jersey 07656              TV Products

Model:          KV-36FS12, KV36FS13, KV-36FS16, KV-36FS17                        No.       520R3
Subject: Transparent Bar In Picture                                              Date: September 17, 2001


Symptom:
 (1343)                With a signal applied to the "S" Input of Video 1, while viewing a component signal
                       connected to the Video 4 input. A transparent bar that travels across the screen can
                       be seen.



Solution:              If the customer should complain of the symptom above please implement the
                       following circuit change, on the UY Board.

                       Add two jumpers to the UY board. Use 24AWG insulated wires as follows:

                       1.      D238 Anode to R1215 ground side.

                       2.      D201 Anode to C1205 ground side.




                               Add jumper between R1215 & Anode of D238

                       Board location:               Component side

                       R1215 (Ground side)           G-7.
                       D238 (Anode side)             G-7.




Reference: TV2001-02                                                                                PRINTED IN USA
TV Products Service Bulletin No. 520R3




                 Add jumper between C1205 Ground side & D201 Anode side

                 Board Location:           Component side

                 C1205 (Ground side)       H-8
                 D201 (Anode side)         G-7
