Image preview - the first page of the document



>> Download TVP0532 documenatation <<

Text preview - extract from the document

S                                          CONFIDENTIAL                                                     CSV-1
Sony Service Company
National Technical Services                Service Bulletin
A Division of Sony Electronics Inc.
Park Ridge, New Jersey 07656               TV Products

Model:          KV-36XBR400                                                          No.       532
Subject: Hole For TV Stand Strap Missing From Rear                                   Date: April 27, 2001
         Cover.


Symptom:
 (116B)                On limited production, the rear cover is missing a hole for securing a TV stand strap
                       with a screw. The TV still meets the minimum standard for stability even when a
                       strap is not used.

Solution:              If the customer complains that there is no screw hole for securing a TV stand strap,
                       follow the procedure below.

                       1- Remove the rear cover from the TV. Attempting to add the screw hole to the
                       cover while it is attached to the TV will likely result in internal damage!

                       2 - Referring to the pictures below, use a 1/8" drill bit (suitable for drilling through
                       plastic) to drill a hole completely through the appropriate area of the rear cover. Be
                       sure to drill the hole straight, not at an angle. Drill from the outside of the cover.

                       Sets possibly affected: serial number range 9068000 - 9081924 Not all sets in this
                       range are missing the screw hole.




             Drill 1/8" hole here.                                             Rear cover after 1/8" hole is drilled.

Reference: SBR0136                                                                                       PRINTED IN USA
