Image preview - the first page of the document



>> Download TVP0534 documenatation <<

Text preview - extract from the document

S                                             CONFIDENTIAL                                             CSV-1
Sony Service Company
National Technical Services                   Service Bulletin
A Division of Sony Electronics Inc.
Park Ridge, New Jersey 07656                  TV Products

Model:          KV-32HS20, KV-32XBR400, KV-32XBR450,                                 No.     534
                KV-36HS20, KV-36XBR400, KV-36XBR450

Subject: Cabinet Buzz Or Rattle At Power On.                                         Date: May 9, 2001


Symptom:
 (6143)                Degauss coil vibration during degauss operation at power on causes a buzzing or
                       rattling noise to be heard from the cabinet. This noise is beyond the normal hum that
                       is briefly heard during the degauss operation.



Solution:              If the customer complains of this symptom, install cushions around the degauss coils
                       at the top and bottom of the set.

                              QUANTITY                     DESCRIPTION                PART
                              REQUIRED                                               NUMBER
                                      2            CUSHION, DEGAUSS COIL            4-084-728-01



                                      Adhesive side.                     Cushion.




                              Adhesive side.




                                                Cushion.




                    Step 1: Position a cushion below the top and bottom degauss coils as shown.
                    Make sure the cushions are equally centered from left to right.




Reference: VEA TV2001-11                                                                            PRINTED IN USA
TV Products Service Bulletin No. 534




       Step 2: Wrap the cushions around the degauss coil as shown.




                                          Make sure top cushion is
                                          centered with cabinet bosses.




                                           Make sure bottom cushion is
                                           centered with center rib.
