Image preview - the first page of the document
sony chassis RG-2-2


>> Download sony chassis RG-2-2 documenatation <<

Text preview - extract from the document
SERVICE MANUAL
MODEL                    COMMANDER     DEST.   CHASSIS NO.   MODEL
                                                                     RG-2 CHASSIS
                                                                     COMMANDER DEST.   CHASSIS NO.


KP-EF61HK2               RM-871        HK      SCC-N71F-A

KP-EF61ME2               RM-871        ME      SCC-N72F-A

KP-EF61MN2               RM-871        GE      SCC-N69F-A

KP-EF61SN2               RM-871        AUS     SCC-N73F-A




MICROFILM
                                                                      PROJECTION TV
 Please file according to model size. ...
   61
KP-EF61HK2/ME2/MN2/SN2             RM-871




                                                       SPECIFICATIONS




   Projection system                                              Number of terminals
                     3 picture tubes, 3 lenses, horizontal          Video           Input: 4, Output: 1
                     in-line system                                                 phono jacks, 1 Vp-p, 75 ohms
   Picture tube      7 inch high-brightness monochrome
                                                                    Audio           Input: 5, Output: 1, VARIABLE
                        tubes (6.3 raster size), with optical
                        coupling and liquidcooling                                  output: 1, phono jacks, 500 mVrms
                        system                                      S video         Input: 2,
   Projection lenses High performance, large-diameter                               Y: 1 Vp-p, 75 ohms, unbalanced,
                        hybrid lens F1.0                                            sync negative,
   Screen size       61 inches                                                      C: 0.286 Vp-p, 75 ohms
   Television system                                                Component video
                     B/G, I, D/K, M                                                 Input: 1, phono jacks
   Color system      PAL, PAL 60, SECAM, NTSC4.43,                                  Y: 1.0 Vp-p, 75 ohms, sync negative
                     NTSC3.58                                                       CB /B-Y: 0.7 Vp-p, 75 ohms
   Channel coverage                                                                 CR/R-Y: 0.7 Vp-p, 75 ohms
                     B/G                                                            Audio: 500 mVrms
                     VHF: E2 to E12                                 Headphone       Output: 1, minijack
                     UHF: E21 to E69                              Power requirement
                     CATV: S01 to S03, S1 to S41                                    110
