Image preview - the first page of the document



>> Download TOSHIBA_BDX1100KE documenatation <<

Text preview - extract from the document

                                                                                File No. 810-201074GR



SERVICE MANUAL



                                                                                                    USB




    Blue-ray Disk PLAYER

                                                         BDX1100KE




The above model is classified as green product(*1), as indicated by the underlined serial
number. This Service Manual describes replacement parts for the green product. When
repairing this green product, use the part(s) described in this manual and lead-free solder (*2).
For (*1) and (*2), see the next page.



   TOSHIBA CORPORATION 2010
                                                                                     Aug. , 2010 GREEN
(*1)                      GREEN PRODUCT PROCUREMENT

The EC is actively promoting the WEEE & RoHS Directives that define standards for recycling
and reuse of Waste Electrical and Electronic Equipment and for the Restriction of the use of
certain Hazardous Substances. From July 1, 2006, the RoHS Directive will prohibit any
marketing of new products containing the restricted substances.
Increasing attention is given to issues related to the global environmental. Toshiba Corporation
recognizes environmental protection as a key management tasks, and is doing its utmost to
enhance and improve the quality and scope of its environmental activities. In line with this,
Toshiba proactively promotes Green Procurement, and seeks to purchase and use products,
parts and materials that have low environmental impacts.


Green procurement of parts is not only confined to manufacture. The same green parts used in
manufacture must also be used as replacement parts.




(*2)                             LEAD-FREE SOLDER

This product is manufactured using lead-free solder as a part of a movement within the
consumer products industry at large to be environmentally responsible. Lead-free solder must
be used in the servicing and repair of this product.


                                           WARNING
                    This product is manufactured using lead free solder.

       DO NOT USE LEAD BASED SOLDER TO REPAIR THIS PRODUCT !
The melting temperature of lead-free solder is higher than that of leaded solder by 86        to
104     (30   to 40 ). Use of a soldering iron designed for lead-based solders to repair product
made with lead-free solder may result in damage to the component and or PCB being
soldered. Great care should be made to ensure high-quality soldering when servicing this
product-especially when soldering large components, through-hole pins, and on PCBs- as the
level of heat required to melt lead-free solder is high.
        . Trouble Shooting Chart......................................................................1-1
        . Block Diagram.................................................................................2-1
        . Electrical Circuit Diagrams
            Front Board...................................................................................3-1
           Power Board................................................................................................3-2

           AV Board.......................................................................................3-3

           SD Card Board.............................................................................................3-4
            Main Board...................................................................................................3-5
    .   . PCB Print-layouts
           Front Board.....................................................................................4-1
            Power Board..................................................................................4-2
          AV Board.......................................................................................................4-3
          SD Card Board..............................................................................................4-4
          Main Board......................................................................................4-5

.        Set Mechanical Exploded view&Parts List............................. ...................5-1
                                                                            ...

.         Technical Specifications...................................................................... -1
                                                                                                       6



.        Revision List......................................................................................9-1

                                                                          Trouble shooting chart

No display on LED, and buttons do not work



                 1R GLVS OD\ RQ /(' DQG
                 EXWWRQV GR QRW ZRUN
