Image preview - the first page of the document
SDP1400B REV[1].01


>> Download SDP1400B REV[1].01 documenatation <<

Text preview - extract from the document
                 FILE NO. 810-200418
                              Rev.01




SERVICE MANUAL



    DVD VIDEO PLAYER
         SD-P1400B




                             Apr.,2004
LASER BEAM CAUTION LABEL




When the power supply is being turned on, you may not remove this laser cautions label. If it removes, radiation of laser

may be received.


PREPARATION OF SERVICING

Pickup Head consists of a laser diode that is very susceptible to external static electrocity.
Although it operates properly after replacement, if it was subject to electrostatic discharge during replacement,
its life might be shortened. When replacing, use a conductive mat, soldering iron with ground wire,etc. to
protect the laser diode from damage by static electricity.
And also, the LSI and IC are same as above.




                                                        Ground conductive
                                                        wrist strap for body.




                   Soldering iron
                   with ground wire
                   or ceramic type




                                                                                1M
                                    Conductive mat
                                                                  The ground resistance
                                                                  between the ground line
                                                                  and the ground is less than 10
                                                                      SWITCH PCB                           HIGH VOLTAGE PCB
        1   NC           1                              1   LI-DC         1
        2   DVDVCC       2                              2   LI-DC         2       1   GND 1
                                                                          3                                                1   HV CRITICAL 1
        3   V20          3                              3   LI-DC                 2   GND 2
                                                                          4                                                2   NC          2
        4   GND          4                              4   GND                   3   RT1 3
                                                                          5                                                3   HV~         3
        5   F            5                              5   GND                   4   B+1 4
                                                                          6                                                4   HV~         4
        6   E            6                              6   GND               JS106
        7   CD/DVD SW    7                              7   TS            7                                            XS101
        8   RF           8                              8   GND           8
        9   C            9                              9   AUXSW         9
       10   D           10                             10   GND          10
       11   B           11                             11   Y1+          11
       12   A           12 XS402                       12   Y1-          12
       13   VRCD        13                             13   C-OUT        13
       14   VRDVD       14                             14   GND          14
       15   DVDMD       15                             15   Y2+          15
       16   CDLD        16                             16   Y2-          16
       17   GND         17                             17   Y-OUT        17
       18   DVDLD       18                             18   Y3+          18            BATTERY PCB
       19   NC          19                             19   Y3-          19
       20   AVCC        20                       JS103 20   VIDEO OUT    20 JS102
       21   FCS-        21
       22   TRK+        22
                                                        1   GND           1                     1    GND   1
       23   TRK-        23                                                              XS301
                                                        2   GND           2                     2    GND   2
       24   FCS+        24
                                                        3   GND           3                     3    HV    3
                                                        4   -14.5V        4                     4    HV    4   XS102
                                                        5   GND           5
       1     SP-        1                                                 6 XS302
                                                 JS104 6    +16.5V
       2     SP+        2                               7                 7                      1   COMS        1
                                                            GND
       3     SL+        3                               8                 8                      2   -16V        2
                                                            GND
       4     SL-        4                               9                 9                      3   SPIO        3
                          XS401                             VDD1-3V
       5     GND        5                              10                10                      4   NC          4
                                                            VDD1-3V
       6     LIMIT      6                              11                11                      5   NC          5
                                                            GND
                                                       12   GND          12                      6   CLD         6
                                                       13   GND          13                      7   MODE1       7
 MECHANISM                                                                                       8               8
                                                       14   GND          14                          GND
                                                       15   GND          15                      9   3.3V        9
    SW101                                              16   BRIGHT-CO    16                     10   GND        10
       1    DC          1                              17   TFT ON/OFF   17                     11   SPOI       11
       2    DCIN        2                              18   TFT-HV       18                     12   GND        12
       3    POWERSW     3                              19   TFT-HV       19                     13   R          13
       4    GND         4                              20   TFT-HV       20                     14   G          14
                                                                                                15   B          15
                        XS101         MAIN PCB          1    VCOMS        1                     16   TF +5V     16
                                                        2    GND          2                     17   TF +5V     17
                                                        3    GND          3                     18   GND        18
                                                        4    GND          4                     19   GND        19
        1
                                                        5    G            5                     20   +13V       20
        2
                                        XS403           6    B            6                     21   I23        21
                            1
                            2
                            3
                            4
                            5
                            6
                            7
                            8




    XS104                                               7    R            7                     22   GND        22
                                                        8    GND          8                     23   GND        23
                            KEYOUT0
                            KEYOUT1
                            KEYOUT2
                            KEYOUT3




POWER PCB B                                             9    MODE2        9                                     24
                            KEYIN3
                            KEYIN2
                            KEYIN1
                            KEYIN0




                                                                                                24   MODE2
                                                       10    MODE1       10                     25   CLS        25
              2 GND




                                                       11    SPOI        11                     26              26
              1 DC




                                                                                                     SPS
                                                       12    SPIO        12                     27   3.3V       27
                                                       13    SPS         13
                            1
                            2
                            3
                            4
                            5
                            6
                            7
                            8




                                                                                                28   GND        28
                                                       14    CLD         14                     29   3.3V       29
                                                 JS105 15    CTR         15 XS303    XS304      30   3.3V       30
                                                       16    CLS         16                                                          LCD
                                                       17    GND         17
                                                       18    GND         18
   POWER PCB A          FUNCTION BUTTON PCB            19    TF +5V      19
                                                       20    TF +5V      20     IF PCB
       OVERALL BLOCK DIAGRAM

                                                                               27MHz

                                                                                                           UPD5100                       TFT MONITOR   HIGH VOLTAGE ASS'Y

                    TC4W53          8M FlashROM          64M SDRAM            74HCU04
                                    MX29LV008TTC-70      NT56V6620C0T-75S                                                  TFT POWER                    DC 12V
                                                                                       27MHz                           +5V -14.5V +16V

                                                                                                                                                            VIDEO OUT
                                            SERVO & DVD PROCESSOR
DV23
                    RF AMP                  MPEG-2 DECODER
                    D2891                   & VIDEO ENCODER
PU mechanism
                                            D2881
                                                                                                                                                            S-VIDEO OUT

                                                      +3.3V

                             +5V

                                                                                   L                                            L
                                                                                                                                                            AUDIO OUT
                                                                                                           AUDIO D/A                      AUDIO AMP
                                                                                   R                       (PCM1742)                      (JRC4558)
 DRIVER
                                                                                                                                R
 (BA5954FP)

                                   DRIVER +5V

                                                                                       AUDIO +5V                                                            PHONE OUT
                                                                                       AUDIO +/-5V                                        PHONE AMP
                                                                                                                                          (JRC4580)

                  DC IN +12V                                                                         BATTERY
                                                           DC / DC                                                              R    L
                                                      (R1224)    (TPS5100)

110~240V                                                                                                                   DC 12V        SPEAKER AMP
                                                                                                                                         (D2822)            SPEAKER LOUT
50/60Hz
                                               DC / DC
               AC                                                      (BQ2057C)               (TPC8207)         (VG202C)
                                               (R1224)
               Adapter                                                                                                                                      SPEAKER ROUT
1. Troubleshooting
1.    No power when turned on.
2.    The initial screen is not displayed on the LCD.
3.    The DVD drive does not work.
4.    The operation of the DVD player stops at initializing display.
5.    Image output stops during the operation.
6.    No sound or abnormal sound comes out from the speakers in the DVD player.
7.    No image or sound comes out from the external output.
8.    No sound comes out from the headphones.
9.    No image or sound is output by external input.
10.   The DVD drive does not operate with the battery.


1.1 No power when turned on.
    When the power is turned on, and if the LED on the front panel does not light green, check
    the following items and repair the defective parts.
     (1) Check the power supply cable
         If the cable is not the supplied one, replace it with the supplied cable and turn on the
         power again.
         If the power supply cable is good, the AC adapter may be defective.
         If the LED does not light after replacing, check the following items.
     (2) Check the AC adapter
         If the AC adapter is not the supplied one, replace it with the supplied AC adapter and
         turn on the power.
         If the AC adapter is good, the power supply boards may be defective.
         If the LED does not light after replacing, check the following items.
     (3) Check the Power and Play buttons
         Press the POWER button or the PLAY button on the DVD player. If the power does
         not turn on, check the following:
               Check the connector of the switch unit in the DVD player.
               (If the connection is loose, repair the connection.)
               Replace the switch unit and turn on the power again.
               If the LED does not light after replacing, check the following items.
     (4) Replace the main board
1.2 The initial screen is not displayed on the LCD.
    If the initial screen is not displayed on the LCD, check the following items.
    (1) Check the LED on the front
         If the LED does not light, proceed to 1.1.
    (2) Check the backlight
         If the backlight does not light up, separate the DVD player into top assembly and
         bottom assembly, and check the LCD harness and the connectors for
         defects.
         If the connector harness is broken:
             Replace the broken harness.
         If the connector harness is not broken:
             Remove the LCD cover and plate of the LCD unit and check the following:
                Check the connector of the FL harness, repair connectors.
                If the connectors are good, replace the FL inverter or the LCD.
    (3) Check the lighting of LCD
         If the LCD does not light, separate the DVD player into the top assembly and bottom
         assembly, and check the LCD harness and the connectors on the main board.
         If the connector is broken:
             Replace the LCD harness or the main board.
         If the connector is not broken:
             Remove the LCD cover and plate of the LCD unit, and check the connection to the
             harness of the LCD unit.
                If a bad connection is found.
                Connect the LCD harness to the LCD unit.
                Other than the above
                Replace the LCD unit or the main board.
1.3 The DVD drive does not work.
    When the DVD drive does not work after the power is turned on, check the following items
    and repair or replace the defective parts.
    (1) Press the DISC cover switch beside the Function button and turn on the
         power. Then check whether or not the optical pick-up lens of the DVD drive
         lights.
         CAUTION: Visible laser radiation when open and interlock defeated. Do not stare into
                         Laser beam.
               The optical pick-up lens lights dim:
                   It is caused by deterioration of the optical pick-up lens. Replace the DVD drive.
               The optical pick-up lens does not light:
                   Check the connectors of the DVD-FFC. Also check the connection to the main
                   board and to the DVD drive.
                Loose connection is found.
                Repair the connection, and then check the operation of the DVD drive again.
                The DVD-FFC is broken.
                Replace the DVD-FFC.
                Other than the above.
                Replace the DVD drive or the main board.
    (2) Insert a DVD disk and turn on the power
         The DVD drive does not work:
            The motor of the DVD drive or the main board is defective. Replace the DVD drive
            or the main board.
         The DVD drive works but the initializing operation of the optical pick-up lens
         does not start (the optical pick-up lens operates twice), or abnormal noise
         sound:
            The DVD drive is defective. Replace the DVD drive.
1.4 The operation of the DVD player stops at initializing display.
    If the DVD player does not work after the initializing screen is displayed, check the
    indication on the screen. Then repair the defect according to it.
    (1) Insert a DVD disk and close the DISC cover, and turn on the power. Then check
         the LCD screen or use an external display.
                The message "loading" is not displayed or the operation stops at the
                message "Loading".
                Since the DVD drive or the main board is defective, check the unit in the following order:
                 1) DVD drive
                 2) Main board
                The message "CHECK DISK" is displayed.
                Check the DVD disk for fingerprints, dirt, etc.
                If the DVD disk is OK, then check the following items:
          1) Check the DVD-FFC
               If a loose connection, repair the connection.
               If it is damaged, replace it with new one.
          2) Other than above
               For other cases, replace the unit in the following order:
                DVD drive (defective optical pick-up)
                Main board
1.5 Image output stops during the operation.
    If the image output from the media in the DVD player stops during the operation, replace
    the DVD drive.


1.6 No sound or abnormal sound comes out from the speakers in the DVD player.
    If no sound comes out from the speakers in the DVD player, check the following:
    (1) Check for moving images on the LCD screen
         Check whether or not the move of image stops in halfway. If it stops, replace the DVD
         drive.
    (2) Check the operation of the DVD drive.
         Check whether or not the DVD drive works. If it stops, replace the DVD drive.
    (3) Check the connection of the speakers.
         Separate the DVD player into the top assembly and bottom assembly, and then check
         the connection of the speaker harnesses to the main board. If a bad connection, repair
         the connection.
         Other than the above, replace the speakers or the main board.


1.7 No image or sound comes out from the external output
    If any image or sound is output from the TV connected by the external cable, replace the
    main board or the connector.
      NOTE: Before this test, make sure the drive works properly.


1.8 No sound comes out from the headphones.
    If no sound comes out from the headphones, replace the main board or the connector.


1.9 No image or sound is output by the external input.
    If any image or sound is output by external input, replace the main board or the connector.


1.10 The DVD drive does not operate with the battery.
    (1) Check the operation with a good battery.
        Install a good battery and make sure the LED lights up orange while the AC adapter is
        connected. When the LED does not light up or blinks, check the connection of the
        battery harness inside the DVD player. If the connection is loose, repair connection. If
        the harness has been connected firmly, replace the main board.
    (2) Other than the above, replace the battery.

        NOTE:
           For this check, use a battery which is not fully charged (because the LED does
           not light when the battery is fully charged.)
           Before this check, make sure other functions work correctly.
      1                                                                    2                                                                                         3                                                                                        4                                                                                         5                                                                                  6                                                                                                          7                                                                                                 8                                                                                                                                         9                         10

    MAIN BOARD CIRCUIT DIAGRAM
A
    (POWER CIRCUIT DIAGRAM)
                                                                                                                                                                                                                                                                                                                                                                                                              2.7k
                                                                                                                                                                                                                                                                                                                                                                                                          R033




                                                                                                                                                                                                                                                                                                                                                                                     2
                                                                                                                                                                                                                                                                                                                                                                                                                     27K
                                                                                                                                                                                                                                                                    N010                                                                                                 VR100                            R032
                                                                                                                                                                                                                                                                                                                                                                           10K
                                                                                                                                                                                                                                                                    R1224N                                                                                                       3




                                                                                                                                                                                                      TFTON/OFF
                                                                                                                                                                                                                                                                                                                                                                                                                                            C024
                                                                                                                                                                                                                               C424                                                                                           N009                                                                                                          1n
                                                                                                                                                                                                                                 NC                       4                     3                                   8                         1                                                     R031
                                                                                                                                                                                                                                                              EXT VOUT                                                    VDD        COM                                                                            10K




                                                                                                                                                                                                                                                                                                                                                                                     1
                                                                                                                                                                                                                       R422 NC                                                                                      7                         2                                                     R042                                                                                                                                                                                                                     L004
                                                                                                                                                                                                                                                                                                                          CH2         INH                                                                           51K                                                                                                                                                                                                    CDRH6D38-330MC
                                                                                                                                                                                                                                                                                2
                                                                                                                                                      R034                                                                                                            GND                                                                                                                           R040
                                                                                                                                                                                                                                                                                                                    6                         3                                                                                                                                                                                                                                                                                                                                                                                                                                                                  TFT-HV
                                                                                                                                                                                                                                                                                                                          CH1         VEE



B
                                                                                                                                                      10K                                                                           +P5V                                                                                                                                                                            NC                                          C026                                                C011
                                                                                                                                                                                                                                                          5                     1                   C025            5                         4                                                                                                                 100n                                                47U/16V                  C066           C068
                                                                                                                                                                                                                               R437                           VIN          CE                       100n                  A           VSS
                                                                                                                                                             C027                                                              10K
                                                                                                                                                             100n        R035                                                                                                                                                     TC4W53
                                                                                                                                                                         1K                                                                                                                                                                                            N011                                             L002                                                                                                                                                                                                                                                                                   L125
                                                                                                                                                                                                                                                                                                              R030                                                     IR7304                                        CDRH6D38-330MC                                                                                                                                                                                                                                   VD115                                    601
                                                                                                                                                                 VD023
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                 V25
                                                                                                                                                                                                                                                                                                                     10
                                                                                                                                                                                                                                                                                                                                                                                           VD022                VD021                                                                                                                                                                                                                                                                                            C128
                                                                                                                                                             4            3                                                                                                                                                                                                              RB060L                                                                                                                                                                                                                                                                       CRG01                                  100U/6V                                                  CB14
                                                                                                                                                                                                              R019                    +P5V                                                                                                                                                                     RB060L                                                                                                                                                                                                                                                                                                                                                 100n
                                                                                                                                                                                                              1K
                                                                                                                                                                          2                                                           R041
                                                                                                                                                                                                                                      10K                                                                                                                                                                                                                                  L501
                                                                                                                                                                                                                                                                                                                                                                                                                                                                           601                                                                                                                                                                          C507
                                                                                                                                                             5            1                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      SAUDIO
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                N005                                      47U/16V
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                             C528                                               BA033
                                                                                                                                                                   FMC3                                                                                                                             C001
                                                                                                                                                                                                                                                                                                           ECJ3YF1C106Z                                                                                                                                                                                                        L005                              100n
                           XS103                                         F002                           FM001     VD002                                                                                                                                                                                                                                                                                                                                                                  N003A                            CDRH6D38-330MC
                           HEC8401-010010                                453003                       LV-R0489                                                                                                                                                                                                                                                                                                                                                                                                                                                                                       1                                       2
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                           IN                 OUT                                                                                                                                                                                DV33
                                                                                                                  IN5402                                                                                                                     VD109                                                                                                                                         R002                                                                                                                                             R046




                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                     GND
                                                                                                                                                                                                                                                                                               R009                                                                                        10                                                                                                                                               3.3k    C055                                                                                                                     L420
                                                                                                                                  VD003                                                                       ECJ3YF1C106Z                   DTC124                                                                                                                                                                                                                                      IR7304                                                     1N                                                                                                                       601
                                                                                                                                                       RB060L                                                  C032
                                                                                                                                                                                                                                                                                                                            VD013                                                                                                                                                                                                                                                                                                                                                                                                                                                                                AV33
                                                                                                                                                                                                                                                                                               2K                                                                                                                                          C007                                                                                                                                                                                                         C102                                                                                    C412




                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                     3




                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                     ECJ3YF1C106Z
C
                                                                                                                                                                                                                                                                                                                        ISS355                                                                                                             100n               N001                                                                                                                  CB62                                                                47U/16V                                                                                                              CB30




                                                                                                                                                                                                                                                                                                                                                                                                                                                      5




                                                                                                                                                                                                                                                                                                                                                                                                                                                                                 4
                                                                                                                                                                         C038                                                                                                                                                                                                                                                                                 R1224N                                                                                          C101                  100n                                                                                                                                                                                     100n
                    DC IN +9V                                                                                                                                              ECJ3YF1C106Z                                                                                                                     VD015                           VD016                                                                                                                                                                                                           100U/6V




                                                                                                                                                                                                                                                                                                                                                                                                                                                        VIN




                                                                                                                                                                                                                                                                                                                                                                                                                                                                                       VOUT EXT
                                                                                                                              VD004                                                                                                                                                                                                         ISS355                                                                                                                                                                          VD01
                                                                                                                              RB060L                                                                                                                                                                                                                                                                                                                                                                                        RB060L                 R056                                           C017                                                                       L402
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                   2.7k                                           100n                                                                       601




                                                                                                                                                                                                                                                                                                                                                                                                                                                                     GND
                                                                                                                                                                                                                                                                                                            UDZS7E-174.7B                   R003




                                                                                                                                                                                                                                                                                                                                                                                                                                                        CE
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                 RV CCIN
                                                                                                                                                             CB3                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                 CB25




                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    ECJ3YF1C106Z
                                                                                                                                                                                                                                                                                                                              2
                                                                                                                                                                    100n                                                                                                                                                                                                                                                                                                                                                                    R047                                                                                                                                                                                                               C413              100n
                                                                                                                                       POWER SWITCH




                                                                                                                                                                                                                                                                                                                     VR003                    12K                                          R114                                                                                                                                             18K




                                                                                                                                                                                                                                                                                                                                                                                                                                                      1


                                                                                                                                                                                                                                                                                                                                                                                                                                                                  2


                                                                                                                                                                                                                                                                                                                                                                                                                                                                                 3
                                                                                                                                                         SW101                                                                                                                                                       10K                                                                   47K
                                                                                                                                                                                                                                                                                                                       3
                                                                                                                                                         ESD10621A
                                                                                                                                                                                                                                                                                                                                                                         R044                   VD112                                                                                                                                                                                                                                                                          C151
                                                                                                                                                                                                                                                                                                                                                                         10K
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                 +P5V
                                                                                                                                                                                             R060                                                                                                                                             R004                                                                                                                                                                                                                                                                                                                                                             CB65                                                                CB74








◦ Jabse Service Manual Search 2020 ◦ Jabse Pravopis ◦ Other service manual resources online : FixyaeServiceinfo
