Image preview - the first page of the document



>> Download M30_part2 documenatation <<

Text preview - extract from the document

4 Replacement Procedures                                                          4.9 Keyboard


4   Replacement Procedures
4.9      Keyboard

Removing the Keyboard

To remove the keyboard, follow the steps below and refer to figures 4-11 to 4-12.

    1. Turn the computer face up and open the display panel.

    2. Insert your finger into the latches between the keyboard brace and the computer, and
       lift up the keyboard brace to unlatch and remove it.

    3. Remove the following screw securing the keyboard and keyboard hold plates. Then
       remove the keyboard hold plate.
