Image preview - the first page of the document
>> Download portege p2000 documenatation <<
Text preview - extract from the document
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Portege
P2000 Series
GENERAL INFORMATION
Tools Required for Proper
Disassembly and Reassembly:
1. Phillips Screwdriver (Size 0)
2. Flat head Screwdriver
3. Case Separator
4. ESD Wrist Strap
5. ESD mat
6. Tweezers
Before attempting any of the following procedures,
make sure that the main battery and AC adaptor is
not connected to the unit and the environment in
which you are working on is protected from
Electro-Static discharge(ESD).
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Portege
P2000 Series
TABLE OF CONTENTS:
1. BATTERY PACK REMOVAL
2. OPTIONAL PC CARD REMOVAL
3. MEMORY MODULE REMOVAL
4. HDD REMOVAL
5. KEYBOARD REMOVAL
6. TOP COVER REMOVAL
7. MINI PCI CARD REMOVAL
8. RTC REMOVAL
9. SPEAKER REMOVAL
10. MODEM BOARD REMOVAL
11. SOUND JACK BOARD REMOVAL
12. SYSTEM BOARD REMOVAL
13. TOUCH PAD REMOVAL
14. DISPLAY MASK REMOVAL
15. FL INVERTER AND LCD REMOVAL
TOSHIBA
Tough Enough for Today's World.
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Portege
P2000 Series
BATTERY PACK REMOVAL OPTIONAL PC CARD REMOVAL
Battery
release
lever
Battery Pack PC card
Eject button
1. Turn the computer upside down as shown. 1. Press the eject button of the PCCard you want to
2. Slide the battery release lever to the left to release remove.
the battery. 2. Press the extended eject button to pop the PC card
3. Lift out the battery. out.
3. Grasp the PC card and remove it.
Note: Before removing any PC Card device, make
sure it is "STOPPED" in the PC Card manager.
MEMORY MEMORY REMOVAL
Memory
cover
M2x2.5 black screws M2x3 black flat head screw Memory module
1. Turn the computer upside down. 3. Remove one M2x3 black flat head screw securing
2. Remove two M2x2.5 black screws securing the memory the memory module.
cover. 4. Disconnect the memory module from the top side
as shown by the arrow above.
TOSHIBA
Tough Enough for Today's World.
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Portege
P2000 Series
HDD REMOVAL
HDD cover
M2x4 black screws HDD connector HDD assembly
1. Turn the computer upside down. 3. Lift up the rubber handle and hold the HDD assembly
2. Remove two M2x4 black screws securing the as shown above.
HDD cover and lift it out. 4. Disconnect the HDD assembly from the
HDD connector.
CAUTION: Be very careful not to press on the TOP or
BOTTOM of the HDD. Pressure can destroy
data or damage the drive.
HDD REMOVAL KEYBOARD REMOVAL
HDD pad
HDD rubber holder
M2x3 black flat head screw
5. Remove the HDD rubber holder and the HDD pad. 1. Turn the computer upside down.
2. Remove one M2x3 black flat head screw securing
the keyboard.
TOSHIBA
Tough Enough for Today's World.
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Portege
P2000 Series
KEYBOARD REMOVAL
Latch
Keyboard
holder
M2x3 silver flat head screws
3. Unlatch the keyboard holder at the top of the keyboard. 4. Remove two M2x3 silver flat head screws securing
the keyboard.
KEYBOARD REMOVAL TOP COVER REMOVAL
M2.5x6 black flat head screws
PJ445
M2x6 M2x4
black black
screws screws
Keyboard
Keyboard cable
5. Lift up the keyboard and lay it on the palm rest. Rubber cover/M2x4 brass screw
6. Disconnect the keyboard cable from PJ445 and lift out 1. Turn the computer upside down.
the keyboard. 2. Remove the rubber cover close to the HDD slot
and remove one M2x4 brass screw.
2. Remove the following screws from the bottom cover:
- 9 M2x6 black screws
- 2 M2.5x6 black flat head screws
- 2 M2x4 black screws and 1 M2x4 brass screw
TOSHIBA
Tough Enough for Today's World.
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Portege
P2000 Series
TOP COVER REMOVAL
Power button/ LED board cable Top cover
PJ7
Internet/In
Touch buttons
cable
PJ8
Flexible
PWB
Touch Pad cable PJ334 PJ9 M2x4 brass screws
3. Turn the computer right side up and open the display. 5. Remove six M2x4 brass screws securing the top
4. Disconnect the following cables by carefully lifting the lever cover.
using from the PCB: 6. Separate the top cover from the bottom cover.
- Touch Pad cable from PJ334
- Flexible PWB from PJ9
- Internet/ In-Touch Buttons cable from PJ8
- Power Button/ LED board cable from PJ7
MINI PCI CARD REMOVAL
White mini coax
Mini PCIcard
interface
adaptor
Mini PCI
connector
clips
Wireless LAN card Black mini coax
1. Disconnect the Mini PCI card interface adaptor from the 3. Disconnect the black and white mini coax from the
system board. Mini PCI wireless LAN card.
2. Carefully lift up the Mini PCI card interface adaptor and 4. Spread the mini PCI connector clips and pull the
turn it over as shown on the next picture. wireless LAN card out of the connector about
30 degrees.
TOSHIBA
Tough Enough for Today's World.
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Portege
P2000 Series
RTC REMOVAL SPEAKER REMOVAL
Glass Tape
PJ10
RTC battery
PJ790 RTC harness Speaker harness Speaker Rubber holder
1. Peel off two strips of glass tape securing the RTC cable. 1. Disconnect the speaker harness from PJ10 on
2. Disconnect the RTC harness from PJ790 and lift it out. the system board.
2. Lift out the speaker and separate the rubber
holder.
MODEM BOARD REMOVAL SOUND JACK BOARD REMOVAL
Modem
board
Modem
harness
Guide pins
HDD/modem
interface
board
M2x4 brass screws Sound jack board
1. Disconnect the modem harness from the modem board. 1. Lift up the sound jack board to free it from the
2. Remove two M2x4 brass screws securing the modem guide pins and pull it out.
board to the HDD/Modem interface board. 2. Turn the board over as shown on the next picture.
3. Disconnect the modem board from PJ3 on the
HDD/modem board
TOSHIBA
Tough Enough for Today's World.
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Portege
P2000 Series
SOUND JACK BOARD REMOVAL SYSTEM BOARD REMOVAL
LAN
harness
PJ352
Sound jack
cable
PJ999 Sound jack board Glass tape PJ35 PJ34 LCD/FLharness
3. Disconnect the sound jack cable from PJ999 on the 1. Peel off the glass tapes securing the modem
sound jack board. harness and the LAN harness.
4. Lift out the sound jack board. 2. Disconnect the LAN harness from PJ352 on the
system board.
3. Disconnect the LCD/FL harness from PJ34 and
PJ35 on the system board.
SYSTEM BOARD REMOVAL
M2x4 brass
flat head
screws
PJ3
PC card slots
PJ11
M2x4 brass flat head screws System board HDD/modem interface cable
4. Remove two M2x4 flat head brass screws securing 7. Disconnect the PC card slots from PJ11 on the system
the system board. board.
5. Remove two M2x4 brass screws securing the 8. Disconnect the HDD/modem interface cable from PJ3
PC card slots. on the system board.
6. Lift out the system board. 9. Remove two cool sheets on the top side of the system
board.
TOSHIBA
Tough Enough for Today's World.
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Portege
P2000 Series
TOUCH PAD REMOVAL
Touch pad board copper tape
Touc pad/
Membrane
cable
RTC/
Speaker
holder
LCD latch assy M2x4 brass screws Touch pad bracket M2x3 silver flat head screws
1. Remove the RTC/Speaker holder. 1. Carefully peel off the copper tape.
2. Remove one M2x4brass screw securing the LCD 2. Remove four M2x3 silver flat head screws securing
latch assembly and lift it out. the Touch pad assembly.
3. Disconnect the Touch pad/ Membrane cable from 3. Lift out the touch pad assembly.
the touch pad board. 4. Separate the touch pad board from the touch pad
bracket.
TOSHIBA
Tough Enough for Today's World.
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Portege
P2000 Series
DISPLAY MASK REMOVAL FL INVERTER AND LCD REMOVAL
LCD cushions FL inverter cable
LCD module
M2x3 silver FL
Flat head inverter
screw board
Display mask
LCD mask seals LCD cable LCD module FL cable
1. Remove one LCD cushions and six LCD mask seals 1. Remove one M2x3 silver flat head screw securing
using a pair of fine-tipped tweezers. the FL inverter board.
2. Remove one M2x3 black flat head screw and 2. Lift up the FL inverter board and disconnect the
six M2x3 silver flat head screws securing the display FL cable from CN2 and the FL inverter cable
mask. from CN1.
3. Lift out the display mask. 3. Carefully rotate out the top of the LCD module
enough to access the LCD/FL cable..
4. Disconnect the LCD/FL cable and lift it out.
TOSHIBA
Tough Enough for Today's World.
