Image preview - the first page of the document
>> Download tecra 9000 documenatation <<
Text preview - extract from the document
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Tecra
9000 Series
GENERAL INFORMATION
Tools Required for Proper
Disassembly and Reassembly:
1. Phillips Screwdriver (Size 0&1)
2. Flat head Screwdriver
3. Security Torx (Size 7)
4. Case Separator
5. ESD Wrist Strap
6. ESD mats
7. Tweezers
Before attempting any of the following procedures,
make sure that the main battery and AC adaptor is
not connected to the unit and the environment in
which you are working on is protected from
Electro-Static Discharge(ESD).
TOSHIBA
Tough Enough for Today's World.
Download service manual and resetter printer at http://printer1.blogspot.com
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Tecra
9000 Series
TABLE OF CONTENTS:
1. BATTERY PACK REMOVAL
2. OPTIONAL PC CARD REMOVAL
3. SELECT BAY REMOVAL
4. CD-R/W/DVD-ROM DRIVE DISASSEMBLY
5. MEMORY MODULE REMOVAL
6. BLUETOOTH CARD REMOVAL
7. HDD REMOVAL
8. KEYBOARD REMOVAL
9. MODEM BOARD REMOVAL
10 WIRELESS LAN CARD REMOVAL
11. TOP COVER REMOVAL
12. COOLING MODULE REMOVAL
13. CPU REMOVAL
14. MICROPHONE REMOVAL
15. SD/SOUND BOARD REMOVAL
16. RTC BATTERY REMOVAL
17. LED/BLUETOOTH BOARD REMOVAL
18. TOP PCB REMOVAL
19. BOTTOM PCB REMOVAL
20. MEMBRANE SWITCH REMOVAL
21. SPEAKERS REMOVAL
22. 14.1'' DISPLAY MASK REMOVAL
23. FL INVERTER AND 14.1'' LCD REMOVAL
TOSHIBA
Tough Enough for Today's World.
Download service manual and resetter printer at http://printer1.blogspot.com
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Tecra
9000 Series
BATTERY PACK REMOVAL OPTIONAL PC CARD REMOVAL
Release
lever
Battery
Pack
PC card
Eject button
1. Turn the computer upside down as shown. 1. Press the eject button for the PC card you want to
2. Slide the battery release lever in the direction of the remove.
arrow. 2. Press the extended eject button to pop the PC Card
3. Lift out the battery. out.
3. Grasp the PC card and remove it.
NOTE: Before removing any PC Card device, make sure
it is "STOPPED" in the PC Card manager.
SELECT BAY REMOVAL CD-R/W/DVD-ROM DRIVE DISASSEMBLY
CD-R/W/DVD-ROM
drive
Base cover
Connector M2x3 silver
screws
Release lever Select bay
device M2x8 silver Connector cover
screws
1. Turn the computer upside down. 1. Remove five M2x3 silver screws securing the base
2. Slide the release lever in the direction of the arrow. cover and lift off the base cover.
3. Pull out the select bay device in the direction of the 2. Remove two M2x8 silver screws securing the
arrow. connector cover.
3. Remove the connector and the connector cover
from the CD- R/W/DVD-ROMdrive.
TOSHIBA
Tough Enough for Today's World.
Download service manual and resetter printer at http://printer1.blogspot.com
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Tecra
9000 Series
MEMORY MODULE REMOVAL
M2.5x2.8
silver flat
head screws
Memory cover Memory clips
1. Turn the computer upside down. 3. Spread the memory clips outward and pull the
2. Remove two M2.5x2.8 silver flat head screws memory module out of the connector on a
and remove the memory cover. 45 degree angle.
BLUETOOTH CARD REMOVAL
Bluetooth cover M2x4 black security torx screw Plastic insulator Bluetooth card Coaxial cable
1. Remove one M2x4 black security torx screw securing 3. Disconnect the coaxial cable from the bluetooth card.
the bluetooth cover. 4. Lift up the plastic insulator to disconnect the card.
2. Lift out the bluetooth cover.
TOSHIBA
Tough Enough for Today's World.
Download service manual and resetter printer at http://printer1.blogspot.com
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Tecra
9000 Series
HDD REMOVAL HDD REMOVAL
M2.5x8 silver screw
HDD cover Plastic Tab HDD pack
1. Turn the computer upside down. 4. Unfold the plastic tab and pull to remove the HDD
2. Remove one M2.5x8 silver screw securing HDD cover. from the bay.
3. Remove the HDD cover.
KEYBOARD REMOVAL
HDD
HDD
bracket
HDD connector M3x4 flat head brass screws M2.5x16 silver screw
5. Remove four M3x4 brass flat head screws securing 1. Turn the computer upside down.
the HDD to the bracket and lift the drive out of the 2. Remove one M2.5x16 silver screw securing the
bracket. keyboard on the bottom cover.
6. Unplug the HDD connector from the drive.
TOSHIBA
Tough Enough for Today's World.
Download service manual and resetter printer at http://printer1.blogspot.com
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Tecra
9000 Series
KEYBOARD REMOVAL
Latch
Keyboard
Keyboard holder M2.5x2.8 silver screws
2. Turn the computer right side up and open the display 4. Remove two M2.5x2.8 silver screws securing the
panel. keyboard.
3. Using the case separator, unlatch the keyboard holder
at the top of the keyboard.
KEYBOARD REMOVAL MODEM BOARD REMOVAL
Keyboard
Modem
board
Keyboard
cable
PJ123
M2x4 brass screws
5. Lift out the keyboard and set it as shown above(Place 1. Remove two M2x4 brass screws securing the
an insulator between the keyboard and the LCD to modem board.
prevent scratches on the LCD). 2. Disconnect the modem board from PJ125 on the
6. Disconnect the keyboard cable from PJ123 on the system board.
system board.
TOSHIBA
Tough Enough for Today's World.
Download service manual and resetter printer at http://printer1.blogspot.com
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Tecra
9000 Series
WIRELESS LAN CARD REMOVAL
Mini-PCI
connector
clips
Mini PCI cover M2.5x4 security torx screw Wireless LAN card Black coax cable White coax cable
1. Remove one M2x4 security torx screw securing 2. Disconnect the black and white coax from the
the mini PCIcover and lift out the cover. wireless LAN card.
3. Spread the Mini-PCI connector clips and pull the
Wireless LAN card out of the connector about
45 degree angle.
TOP COVER REMOVAL
M2.5x8 silver screws Glass tape M2.5x14 black screw LCD/FL cable
M2.5x4
M2.5x2.8
black flat
silver flat PJ127
head
head screws
screw
M2x12 Speaker
silver cable
screws
M2.5x8 silver screws Membrane switch cable PJ122
M2.5x16 silver screws 3. Disconnect the speaker cable from PJ127 and the
1. Turn the computer upside down and remove the membrane switch cable from PJ122 on the top board
following screws: 4. Remove the glass tape securing the LCD/FL cable
-2 M2.5x2.8 silver flat head screws and disconnect the cable from the bottom board.
-1 M2.5x4 black flat head screw 5. Remove two M2.5x8 silver screws and one M2.5x14
-4 M2.5x8 silver screws black screw from the keyboard area.
-4 M2x12 silver screws 5. Lift out the top cover assembly.
-6 M2.5x16 silver screws Note: When installing the top cover, ensure that the bluetooth
2. Turn the computer right side up and open the display. coaxial cable is properly routed to the Bluetooth slot.
TOSHIBA
Tough Enough for Today's World.
Download service manual and resetter printer at http://printer1.blogspot.com
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Tecra
9000 Series
COOLING MODULE REMOVAL CPU REMOVAL
Cooling
module
Fan cable
CPU
M2.5x10
black flat
head screws
Open Close
Glass tape PJ770 Thermal conductor CPU lock
1. Remove the glass tape securing the fan cable and 1. Peel off the thermal conductor.
disconnect the cable from PJ770 on the top board. 2. Insert a flat head screwdriver and rotate it
2. Remove four M2x10 black flat head screws securing counter-clockwise to unlock the CPU lock.
the cooling module. 3. Lift out the CPU.
3. Lift out the cooling module.
MICROPHONE REMOVAL SD/SOUND BOARD REMOVAL
SD
interface
cable
PJ1001
Sound
interface
cable
PJ1000
Microphone Microphone cable PJ1003 SD/Sound board M2.5x4 brass screws
1. Disconnect the microphone cable from PJ1003 on the 1. Disconnect the SD interface cable from PJ1001 and
SD/Sound board. sound interface cable from PJ1000 on the
2. Lift out the microphone. SD/sound board.
2. Remove two M2.5x4 brass screws securing the
SD/Sound board.
3. Lift out the SD/Sound board.
TOSHIBA
Tough Enough for Today's World.
Download service manual and resetter printer at http://printer1.blogspot.com
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Tecra
9000 Series
RTC BATTERY REMOVAL LED/BLUETOOTH BOARD REMOVAL
M2.5x8
silver
screw
RTC
battery
PJ5 RTC cable Plastic insulator LED/Bluetooth board M2.5x4 brass screws
1. Remove the plastic insulator. 1. Remove two M2.5x4 brass screws and one M2.5x8
2. Disconnect the RTC cable from PJ5 on the silver screw securing the LED/Bluetooth board.
LED/Bluetooth board. 2. Disconnect the LED/Bluetooth board from PJ105
3. Lift out the RTC battery. on the top PCB.
TOP PCB REMOVAL
Modem cable
This is where
top and bottom
board interconects
PJ801
Sound interface
cable
Power
cable PC card slot
SD interface cable
M2.5x16 black screw M2.5x4 brass screws
1. Disconnect the power cable from PJ801 on the top PCB. 4. Remove the PC card slot from PJ117 on the top PCB.
2. Remove two M2.5x4 brass screws and one M2.5x16 5. Disconnect the following cables from the top PCB:
black screw securing the top PCB. -Sound interface cable from PJ102
3. Gently lift up the right side of the top board to disconnect -SD interface cable from PJ103
from PJ19 on the top PCB. -Modem cable from PJ126
TOSHIBA
Tough Enough for Today's World.
Download service manual and resetter printer at http://printer1.blogspot.com
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Tecra
9000 Series
BOTTOM PCB REMOVAL MEMBRANE SWITCH REMOVAL
M2.5x4
brass
screws
Membrane
switch assy
Bottom
board
PJ18 Battery harness M2.5x3 silver screws
1. Disconnect the battery harness from PJ18 on the 1. Remove three M2.5x3 flat head silver screws
bottom PCB. securing the membrane switch.
2. Remove five M2.5x4 brass screws securing the bottom 2. Lift out the membrane switch assembly.
PCB.
3. Lift out the bottom PCB.
SPEAKERS REMOVAL
Left and right
speakers
M2.5x4 brass screws
1. Remove four M2.5x4 brass screws securing the left
and right speakers.
2. Lift out the speakers.
TOSHIBA
Tough Enough for Today's World.
Download service manual and resetter printer at http://printer1.blogspot.com
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Tecra
9000 Series
14.1" DISPLAY MASK REMOVAL FL INVERTER AND 14.1" LCD REMOVAL
LCD module
Latch
Mask Mask
seals seals
Display
mask
M2x4
LCD brass M2x4
screws brass
screws
LCD/
FL cable FL inverter board M2x3 silver screw FL cable
Mask seals
1. Remove two mask seals at the bottom corners of the 1. Remove one M2x2.8 silver screw securing the
display assembly using a pair of fine-tipped tweezers. FL inverter board.
2. Remove two M2.5x6 flat head brass screws securing 2. Carefully lift up the FL inverter board and
the display mask. disconnect the LCD/FL cable from CN1 and the
3. There are 23 latches securing the display mask. FL cable from CN2.
Carefully insert your fingers between the mask and the 3. Remove four mask seals to expose four screws
LCD panel and pry open the latches starting from the securing the LCD module assembly.
six top latches, to the five latches on each right 4. Remove four M2X2.8 brass screws securing the
and left sides, ending with the bottom seven latches. LCD module assembly.
5. Carefully rotate out the top of the LCD module
enough to access the display cable
6. Peel off the tape securing the LCD/FL cable and
disconnect the cable.
7. Remove four M2x2.8 silver screws securing the
right and left LCD brackets.
