Image preview - the first page of the document
Toshiba_32WL66P_37WL66P_42WL66P_32WLG66_32WLT66_37WLG66_37WLT66_42WLG66_42WLT66_LVDS_cable_repair_tips


>> Download Toshiba_32WL66P_37WL66P_42WL66P_32WLG66_32WLT66_37WLG66_37WLT66_42WLG66_42WLT66_LVDS_cable_repair_tips documenatation <<

Text preview - extract from the document
Technical Bulletin
Model(s)
32WL66P, 37WL66P, 42WL66P, 32WLG66, 32WLT66, 37WLG66, 37WLT66, 42WLG66, 42WLT66
Symptom
Subject: LVDS lead wire dressing
Cause
LVDS lead wire with a conductive tape should be dressed to the chassis GND
with lead wire clamper after servicing to meet EMC requirement.
Refer to the picture for actual wiring dressing.
Note: The picture for the lead wire dressing shows some of representative model
only. Follow the actual model original lead wire dressing.
Cure:
