Image preview - the first page of the document
toshiba-cn36v51-cz32v61-36v61


>> Download toshiba-cn36v51-cz32v61-36v61 documenatation <<

Text preview - extract from the document
                                                 SAFETY PRECAUTIONS
                                                                                                                                                                                                                                                                                              5266
                                                                                                                                                                                                                                                                           Technical Service Data
SERVICE WARNING                                                                   SAFETY CHECKS  FIRE AND SHOCK HAZARD
Only qualified service technicians who are familiar with safety checks            Cold Leakage Checks for Receivers with Isolated Ground
                                                                                                                                                                                                                                                                                             TOSHIBA




                                                                                                                                                                      SET 5266
                                                                                                                                                                                                                                                                                Model CZ36V61 (Chassis TAC9922)
and guidelines should perform service work. Before replacing parts,
disconnect power source to protect electrostatically sensitive parts. Do          Unplug the AC cord, connect a jumper across the plug prongs, and turn
not attempt to modify any circuit unless so recommended by the                    the power switch on (if applicable). Use an ohmmeter to measure the
                                                                                                                                                                                                                                  INDEX
manufacturer. When servicing the receiver, use an isolation transformer           resistance between the jumped AC plug and any exposed metal cabinet
between the line cord and power receptacle.                                       parts such as antenna screw heads, control shafts, or handle brackets.

SERVICING THE HIGH VOLTAGE AND CRT
                                                                                  Exposed metal parts with a return path should measure between 1M                                                      High Voltage Shutdown Test .................... 1
                                                                                  ohms and 5.2M ohms. Parts without a return path must measure infinity.                                                Important Parts Information ..................... 1
                                                                                  Hot Leakage Current Check
Use EXTREME CAUTION when servicing the high voltage circuits. To                                                                                                                                        Miscellaneous Adjustments ..................... 1
discharge static high voltage, connect a 10K ohms resistor in series with a                                                                                                                             Parts List ................................................... 4
test lead between the receiver ground and CRT anode lead. DO NOT lift             Plug the AC cord directly into an AC outlet. DO NOT use an isolation
                                                                                  transformer. Use a 1500 ohms, 10W resistor in parallel with a .15
