Image preview - the first page of the document
toshiba__cn27e90-training_manual


>> Download toshiba__cn27e90-training_manual documenatation <<

Text preview - extract from the document
                          NTDCTV05




TECHNICAL TRAINING MANUAL
N5SS (TG-1, C) CHASSIS

  COLOR TELEVISION
        CN27E90, CX32E70
        CN32E90, CN35E15
        CF35E50, CX35E60
        CX35E70, CX35E81
        CN35E90, CN35E95




                  PRINTED IN JAPAN Aug. 1995 So
                                                            Contents
SECTION I
OUTLINE ...................................................................... 6
1. OUTLINE OF N5SS CHASSIS (CN32E90, CN35E90) .................................................................... 7
2. PC BOARD CONFIGURATION ........................................................................................................ 7
3. MAJOR SPECIFICATIONS (NEW FUNCTIONS IN ADDITION TO THOSE OF N5SS) ........ 7
4. MODIFICATIONS ON CHASSIS ..................................................................................................... 7
5. CONSTRUCTION OF CHASSIS ...................................................................................................... 8
6. LOCATION OF CONTROLS ............................................................................................................ 9
7. CN32D90 BLOCK DIAGRAM ......................................................................................................... 13
8. [US, CANADA] SPECIFICATION FOR MODEL's 1995 ............................................................ 14


SECTION II
TUNER, IF/MTS/S.PRO MODULE ......................... 16
1. CIRCUIT BLOCK ............................................................................................................................. 17
2. TUNER ................................................................................................................................................ 18
3. IF/MTS/S.PRO MODULE ................................................................................................................. 19
4. PIP TUNER ......................................................................................................................................... 23


SECTION III
CHANNEL SELECTION CIRCUIT ........................ 24
1. OUTLINE OF CHANNEL SELECTION CIRCUIT SYSTEM .................................................... 25
2. OPERATION OF CHANNEL SELECTION CIRCUIT ................................................................ 25
3. MICROCOMPUTER ......................................................................................................................... 26
4. MICROCOMPUTER TERMINAL FUNCTION ........................................................................... 27
5. EEPROM (QA02) ............................................................................................................................... 29
6. ON SCREEN FUNCTION ................................................................................................................. 29
7. SYSTEM BLOCK DIAGRAM ......................................................................................................... 30
8. LOCAL KEY DETECTION METHOD .......................................................................................... 31
9. REMOTE CONTROL CODE ASSIGNMENT ............................................................................... 32
10. ENTERING TO SERVICE MODE ................................................................................................ 35
11. TEST SIGNAL SELECTION ......................................................................................................... 35
12. SERVICE ADJUSTMENT .............................................................................................................. 35
13. FAILURE DIAGNOSIS PROCEDURE ......................................................................................... 36
14. TROUBLE SHOOTING CHART .................................................................................................. 38


SECTION IV
AUDIO OUTPUT CIRCUIT ..................................... 41
1. OUTLINE ............................................................................................................................................ 42
2. AUDIO OUT IC .................................................................................................................................. 43

                                                                            2
SECTION V
A/V SWITCHING CIRCUIT .................................... 44
1. OUTLINE ............................................................................................................................................ 45
2. IN / OUT TERMINALS ..................................................................................................................... 45
3. CIRCUIT OPERATION .................................................................................................................... 45


SECTION VI
VIDEO PROCESSING CIRCUIT ............................ 47
1. OUTLINE ............................................................................................................................................ 48
2. SIGNAL FLOW .................................................................................................................................. 48
3. CIRCUIT OPERATION .................................................................................................................... 48


SECTION VII
V/C/D/IC ...................................................................... 52
1. OUTLINE ............................................................................................................................................ 53
2. LARGE SCALE EMPLOYMENT OF BUS CONTROL OF PARAMETER FOR PICTURE
    CONTROLS ...................................................................................................................................... 53
3. EMPLOYMENT OF CONTAINING EACH VIDEO BAND FILTER INSIDE.......................... 53
4. EMPLOYMENT OF CONTAINING EACH FILTER (FOR S/H) INSIDE................................. 53
5. LOW COST OF IC ............................................................................................................................ 53


SECTION VIII
PIP MODULE ............................................................. 55

SECTION IX
SYNC SEPARATION, H-AFC,
  H-OSCILLATOR CIRCUITS .............................. 58
1. SYNC SEPARATION CIRCUIT ...................................................................................................... 59
2. H AFC (Automatic Frequency Control) CIRCUIT ......................................................................... 60
3. H OSCILLATOR CIRCUIT ............................................................................................................. 61


SECTION X
VERTICAL OUTPUT CIRCUIT ............................. 63
1. OUTLINE ............................................................................................................................................ 64
2. V OUTPUT CIRCUIT ....................................................................................................................... 65


                                                                           3
SECTION XI
HORIZONTAL DEFLECTION CIRCUIT.............. 69
1. OUTLINE ............................................................................................................................................ 70
2. HORIZONTAL DRIVE CIRCUIT ................................................................................................... 70
3. BASIC OPERATION OF HORIZONTAL DRIVE ........................................................................ 71
4. HORIZONTAL OUTPUT CIRCUIT ............................................................................................... 74
5. HIGH VOLTAGE GENERATION CIRCUIT ................................................................................. 79
6. X-RAY PROTECTION CIRCUIT ................................................................................................... 82
7. OVER CURRENT PROTECTION CIRCUIT................................................................................ 83
8. KINK CORRECTION CIRCUIT ..................................................................................................... 84


SECTION XII
DEFLECTION DISTORTION CORRECTION
  CIRCUIT (Side DPC Circuit) .............................. 85
1. DEFLECTION DISTORTION CORRECTION IC (TA8859P) .................................................... 86
2. SIDE DPC ............................................................................................................................................ 87
3. DIODE MODULATOR CIRCUIT ................................................................................................... 88
4. ACTUAL CIRCUIT ........................................................................................................................... 89


SECTION XIII
CLOSED CAPTION/EDS CIRCUIT ....................... 92
1. OUTLINE ............................................................................................................................................ 93
2. DATA TRANSMISSION FORMAT ................................................................................................ 93
3. DISPLAY FORMAT ........................................................................................................................... 94
4. CIRCUIT OPERATION .................................................................................................................... 95


SECTION XIV
POWER CIRCUIT ..................................................... 98
1. OUTLINE ............................................................................................................................................ 99
2. RECTIFYING CIRCUIT AND STANDBY POWER SUPPLY ................................................... 100
3. MAIN SUPPLY CIRCUIT............................................................................................................... 100
4. OUTLINE OF CURRENT RESONANT TYPE SUPPLY ........................................................... 101
5. FUNDAMENTAL THEORY ........................................................................................................... 101
6. ACTUAL CIRCUIT ......................................................................................................................... 102
7. OTHER POWER CIRCUIT ........................................................................................................... 105
8. PROTECTOR MODULE (Z801) .................................................................................................... 106




                                                                            4
SECTION XV
DSP CIRCUIT .......................................................... 109
1. ORIGINS OF DOLBY SURROUND ............................................................................................. 110
2. THE DOLBY MP MATRIX ............................................................................................................ 110
3. THE DOLBY SURROUND DECODER ......................................................................................... 111
4. DSP CIRCUIT ................................................................................................................................... 111
5. DSP (Digital Surround Processor) IC ............................................................................................. 114
6. SURROUND CIRCUIT ................................................................................................................... 116
7. INPUT BALANCE CIRCUIT ......................................................................................................... 116
8. MATRIX CIRCUIT ......................................................................................................................... 117
9. FILTER CIRCUIT (ANTI-ALIAS FILTER)................................................................................. 117
10. DSP CIRCUIT (DELAY) ............................................................................................................... 118
11. 7 kHz LOW PASS FILTER ........................................................................................................... 119
12. DOLBY NR CIRCUIT ................................................................................................................... 120
13. DSP FRONT ADDITION CIRCUIT ............................................................................................ 121
14. BUS CONVERTER ........................................................................................................................ 122
15. NEUTRAL BIAS ............................................................................................................................ 122
16. AUDIO OUTPUT AMPLIFIER (For Rear SP) .......................................................................... 123
17. TROUBLESHOOTING CHART ................................................................................................. 124


SECTION XVI
FAILURE DIAGNOSIS PROCEDURES ............... 125
1. H STARTING CIRCUIT FAILURE DIAGNOSIS PROCEDURES........................................... 126
2. DEFLECTION CIRCUIT FAILURE DIAGNOSIS PROCEDURES ......................................... 127
3. LEFT-RIGHT PIN-CUSHION DISTORTION CORRECTION CIRCUIT .............................. 128
4. X-RAY PROTECTION CIRCUIT FAILURE DIAGNOSIS PROCEDURES ........................... 129
5. PROTECTION CIRCUIT DIAGNOSIS PROCEDURE ............................................................. 130
6. VIDEO CIRCUIT DIAGNOSIS PROCEDURES ......................................................................... 131




                                                                         5
SECTION I
OUTLINE




  6
1. OUTLINE OF N5SS CHASSIS                                      3. MAJOR SPECIFICATIONS (NEW
   (CN32E90, CN35E90)                                              FUNCTIONS IN ADDITION TO THOSE
                                                                   OF N5SS)
The N5SS chassis is a complete bus control type
chassis where the deflection circuit is controlled by a newly   (1) EOS (Extended-Data-Service)
developed I2C-bus line control system.                          (2) Center-Ch-Audio-Input provided

2. PC BOARD CONFIGURATION                                       4. MODIFICATIONS ON CHASSIS
                                                                (1) Serviceability improved with direct, front access system
(1) Signal unit                                                     employed.
(2) Power/def unit                                              (2) One touch cabinet securing (CN32E90) to the chassis.
(3) A/V, CRT-D, SP-TERM                                         (3) Improved serviceability with the bus control system
(4) CCD, comb (CN32E90)                                             employed for the defection circuits.
    Digital comb (CN35E90)                                      (4) Improved serviceability with the white balance bus
(5) D.S.P unit                                                      control system employed.
(6) C.C, EDS/R.G.B SW                                           (5) Digital comb/CCD miniaturized into a socketable size.




                                                          7
               5. CONSTRUCTION OF CHASSIS


                                                                                             DPC circuit


                                                                                                   CCD circuit
                                                                                                        PIP circuit
                                                                   SIGNAL circuit
                                                                                                             EDS, RGB SW
                                                                                                             circuit
                                                                         IF/MTS/A-PRO
                                                                         module
                                                                              AUDIO OUT

                                                                                                                                             CRT circuit


                                            REAR AMP circuit




                                       CONVERTER trans
                                                                                                                               A/V circuit
8
    Fig. 1-1




                                                                                                                           RF SW




                POWER/DEF circuit



                                                                                                   V. OUT


                                                                                     DPC circuit
                                    H.OUT




                                                     H.OUT trans
6. LOCATION OF CONTROLS
6-1. TV Set

For specific use of each control, consult the corresponding page numbers in brackets.




                           Front View




                                                                                                            POWER indicator
                                                                                           POWER




                                                                                             POWER button
                                                                                        Remote sensor




                                    Press to open
                                    the door




                  Behind the door




                       VIDEO/AUDIO IN
                       jacks
