Image preview - the first page of the document



>> Download Tektronix_TLA7NA_Series_Datasheet documenatation <<

Text preview - extract from the document

Tektronix Logic Analyzers
TLA7NAx Logic Analyzer Modules Data Sheet
                                                                                  Applications
                                                                                     Hardware Debug and Verification
                                                                                     Processor/Bus Debug and Verification Including Source Synchronous
                                                                                     Clocking
                                                                                     Embedded Software Integration, Debug and Verification

                                                                                  Breakthrough Solutions for Real-time Digital
                                                                                  Systems Analysis
                                                                                  The TLA7NAx Logic Analyzer Module speeds debug and verification of
                                                                                  fast buses and complex embedded systems with an industry-leading
                                                                                  combination of acquisition, triggering and analysis capabilities. Quickly
                                                                                  debug fast buses like DDR memory and PCI-X, using long record length
                                                                                  to capture intermittent events over a wide time window and MagniVu
                                                                                  high-speed timing to simultaneously capture glitches as small as 125 ps.
                                                                                  The TLA7NAx module's advanced triggering capabilities allow you to
                                                                                  trigger on microprocessor operation failures, which speeds troubleshooting
                                                                                  of embedded systems incorporating microprocessors such as the
                                                                                  PowerQUICCIII. Additional tools like source code and protocol analysis
The TLA Series logic analyzer modules offer the highest performance for today's   and listing view make monitoring and debugging processor operation faster
demanding applications.                                                           and easier.

Features & Benefits
   34/68/102/136 Channel Logic Analyzers with up to 128 Mb Record
   Length to Capture Long Periods of Time
   500 ps (2 GHz)/32 Mb Timing Analysis to Track Down Elusive Timing
   Problems Faster
   125 ps (8 GHz) MagniVuTM Acquisition simultaneous with Timing or State
   Acquisition to Find Difficult Problems Quickly
   Up to 450 MHz State Acquisition Analysis of Synchronous Digital Circuits
   Glitch and Setup/Hold Violation Triggering and Display Finds and
   Displays Elusive Hardware Problems
   Transitional Storage Extends the Signal Analysis Capture Time
   Connectorless Probing System With 0.5 pF Capacitive Loading
   Eliminates Need For Onboard Connectors, Minimizes Intrusion on
   Circuits and is Ideal for Differential Signal Applications
   Broad Processor and Bus Support
Data Sheet



Characteristics                                                                       State Record Length with Time Stamps
                                                                                      Full Channel                         Half Channel*1
General
                                                                                      512 Kb Standard                      1 Mb
Number of Channels (all channels are acquired including clocks)
