Image preview - the first page of the document
>> Download Maxtor DiamondMax Plus 9 SATA-150 Quick Specs documenatation <<
Text preview - extract from the document
QUICKSPECS
DiamondMax Plus 9 SATA/150 7200 RPM:
CAPACITIES:
MODEL ACT CYLS HDS:SECT MAX CYLS MAXLBA GB CAPACITY
6Y060M0 119,150 16:63 16,383 120,103,200 60GB
6Y080M0 158,816 16:63 16,383 160,086,528 80GB
6Y120M0 238,216 16:63 16,383 240,121,728 120GB
6Y160M0 317,632 16:63 16,383 320,173,056 160GB
6Y200M0 395,136 16:63 16,383 398,297,088 200GB
NOTE: NEVER enter more than 16,383 cylinders in the system BIOS. This may potentially cause data loss.
SATA = Serial ATA
Attaching SATA Power Cables: Key Features:
