Image preview - the first page of the document
>> Download Maxtor DiamondMax VL20 documenatation <<
Text preview - extract from the document
R
QUICKSPECS
DiamondMax VL 20 Ultra DMA 66:
Model Number Cyls Hds Sect Size GB
Misc. Drive Info:
94091U8 16,383 16 63 40.9 GB
NEVER enter more than 16,383 cylinders in the system
93071U6 16,383 16 63 30.7 GB BIOS. This may potentially cause data loss.
92561U5 16,383 16 63 25.6 GB
GB = 1 billion bytes. Total accessible capacity varies
92041U4 16,383 16 63 20.4 GB depending on operating environment.
91731U4 16,383 16 63 17.3 GB For more information on cylinder limitations, BIOS, step-
91531U3 16,383 16 63 15.3 GB by-step installation procedures, troubleshooting procedures
and more go to the Maxtor.com Knowledge Base.
91361U3 16,383 16 63 13.6 GB
91021U2 16,383 16 63 10.2 GB
90841U2 16,383 16 63 8.4 GB
90651U2 12,495 16 63 6.5 GB
Jumper Settings:
(Master) - The vertical jumper over the J50 pins is configuring the drive as a
Master. The horizontal jumper over the J48 and J46 pins is in the Storage
position.
(Master with CLJ) - The vertical jumper over the J50 pins is configuring the
drive as a Master. The vertical jumper over the J46 pins is in the Cylinder
Limitation position (CLJ).
(Slave) - No jumper is required to configure the drive as a Slave. The jumpers
over the J48, J46, J44 and J42 positions are both in the storage position.
(Slave with CLJ) - The jumper over the J44 and J42 positions is in the storage
position. The jumper over the J46 pins is in the Cylinder Limitation position
(CLJ).
(Cable Select) - The jumper over the J48 position is configuring the drive for
Cable Select. The jumper over the J44 and J42 pins is in the storage position.
(Cable Select with CLJ) - The jumper over the J48 position is configuring the
drive for Cable Select. The jumper over the J46 pins is in the Cylinder Limitation
position (CLJ).
Key Features:
