Image preview - the first page of the document
DSP56000UM


>> Download DSP56000UM documenatation <<

Text preview - extract from the document
                              DSP56000
                       24-BIT
            DIGITAL SIGNAL PROCESSOR
                  FAMILY MANUAL




Motorola, Inc.
Semiconductor Products Sector
DSP Division
6501 William Cannon Drive, West
Austin, Texas 78735-8598
                                                                                  Order this document by
MOTOROLA                                                                            DSP56KFAMUM/AD

SEMICONDUCTOR
TECHNICAL DATA
                                                              DSP56K Family
Addendum to
24-bit Digital Signal Processor
Family Manual
This document, containing changes, additional features, further explanations, and clarifications, is
a supplement to the original document:

DSP56KFAMUM/AD                      Family Manual       DSP56K Family
                                                        24-bit Digital Signal Processors

Change the following:
Page 11-4, Section 11.2.1 - Delete "4. NeXTTM under Mach".
Page A-83, third line - Replace "1;leN;le24" with "1N24"
Page A-104, Under the "Operation:" heading - Replace "D -1  D" with "D+1  D".
Page A-104, Second sentence after "Description:" heading - Replace "One is added from the LSB
of D." with "One is added to the LSB of D; i.e. bit 0 of A0 or B0."
Page A-130, First symbolic description under the "Operation:" heading - Replace "If S[n]=0" with
"If S[n]=1".
Page A-218, Timing description - Replace "Timing: 2+mvp oscillator clock cycles" with "Timing:
6 + ea + ap oscillator clock cycles".
Page A-219, Timing description - Replace "Timing: 2+mvp oscillator clock cycles" with "Timing:
6 + ea + ap oscillator clock cycles".
Page A-225, Timing description - Replace "Timing: 4+mvp oscillator clock cycles" with "Timing:
2+mvp oscillator clock cycles".
Page A-261, Timing description - Replace "Timing: 4 oscillator clock cycles" with "Timing: 2+mvp
oscillator clock cycles".
Page A-261, Memory description - Replace "Memory: 1 program words" with "Memory: 1+ mv
program words".
Page B-11, An inch below the middle of the page - Replace the "cir" instruction with "clr".
Page B-16, 7th instruction from bottom - Replace "lsl   A,n0" with "lsl   B A,n0".
