Image preview - the first page of the document
>> Download S.G_TM4400_CH5 documenatation <<
Text preview - extract from the document
Chapter 5
Jumper and Connector Locations
Top View
1 Keyboard Connector CN5 7 3 in 1 Connector CN10
2 Bluetooth Board Connector CN6 8 Speaker Connector CN12
3 LCD Cable Connector CN2 9 Internal Microphone Connector CN11
4 LED Board Connector CN3 10 Modem Board Connector CN9
Chapter 5 87
5 Lid Switch SW2 11 Touchpad Board Connector CN8
6 Modem Cable Connector CN4
88 Chapter 5
Bottom View
1 Power Jack CN13 16 Audio Cable Connector CN34
2 CRT CN14 17 Line-in Connector CN39
3 Docking CN15 18 Headphone Out Connector CN37
4 Audio Cable Connector CN16 19 Microphone-in Connector CN38
5 Main Battery Connector CN18 20 USB Connector CN36
6 ODD Connector CN19 21 IEEE 1394 Connector CN35
7 Media Bay Connector CN23 22 PCMCIA CN30
8 Mini PCI Slot CN24 23 USB Connector CN28
9 Second Battery Connector CN26 24 CPU Socket U41
10 RTC Battery Connector CN31 25 USB Connector CN27
11 DDR DIMM Connector CN32 26 S-Video CN25
12 HDD Connector CN33 27 RJ45 and RJ11 Connector CN22
13 IR U53 28 LAN Cable Connector CN21
Chapter 5 89
14 Bluetooth Switch SW4 29 FAN Connector CN20
15 Wireless Switch SW3 30 LAN Cable Connector CN17
90 Chapter 5
