Image preview - the first page of the document



>> Download Repairing-LCD-Main-Board-1966 documenatation <<

Text preview - extract from the document

Repairing Apple Studio Display M2454 LCD Main Board




    Repairing Apple Studio Display M2454 LCD Main
                        Board
         Tools used in this guide
             2mm Hex Screwdriver
             Phillips #2 Screwdriver



                                          Step 1 - LCD Main Board
                                            Locate the four hex head screws located on the corners
                                            of the back panel.
                                                   Remove the screws with a 2mm hex screwdriver.




                                          Step 2
                                            Locate the three 2mm hex screws located on the back
                                            stand of the monitor.
                                                   These screws must be removed with the 2mm
                                                   hex screwdriver in order for the back panel to be
                                                   removed.
