Image preview - the first page of the document
>> Download Repairing-Main-Computer-Cable-2092 documenatation <<
Text preview - extract from the document
Repairing Apple Studio Display M2454 Main Computer Cable
Repairing Apple Studio Display M2454 Main
Computer Cable
Tools used in this guide
2mm Hex Screwdriver
Phillips #2 Screwdriver
Step 1 - Main Computer Cable
First, the back panel needs to be removed to access
the cable connectors.
Locate the three 2mm hex screws located on the
top of the stand and remove them.
Now locate and remove the four 2mm hex screws
on the corners of the back panel.
Now remove the back panels while pulling the cable
through them without damaging either part.
Step 2
Remove the metal back plate by using the #2 philips
head screwdriver and removing the top screw.
Now remove the two other philips screws located below
the cable with the philips head screwdriver.
With all the screws removed, push the metal plate
towards the bottom of the monitor to release the clips
holding it to the monitor.
Pull the metal plate away.
