Image preview - the first page of the document



>> Download Disassembling-Lower-Case-3216 documenatation <<

Text preview - extract from the document

Disassembling Apple Time Capsule Lower Case




     Disassembling Apple Time Capsule Lower Case
         Tools used in this guide
             Heat gun or hair dryer
             Phillips #00 Screwdriver
             Spudger



                                         Step 1 - Lower Case
                                              Place the unit bottom up on your work surface. Use a
                                              cloth or similar to protect it from scratches.
                                              Use a heat gun, hair dryer or similar in order to weaken
                                              the adhesives in the tape that hold it in place.
                                                   Start in a corner, it can be tricky to get a good grip
                                                   at first.
                                                   Progress slowly not to tear the tape, but do not
                                                   over heat the unit.
                                                   You will tear some of the tape, don't worry to
                                                   much about it. It will still hold in place.
