Image preview - the first page of the document
>> Download Installing-Hard-Drive-2750 documenatation <<
Text preview - extract from the document
Replacing Apple Time Capsule HDD
Replacing Apple Time Capsule HDD
Tools used in this guide Parts relevant to this guide
Heat gun or hair dryer Hard Drive SATA
Phillips #00 Screwdriver
Spudger
Step 1 - disassembly Lower Case
Place the unit bottom up on your work surface. Use a
cloth or similar to protect it from scratches.
Use a heat gun, hair dryer or similar in order to weaken
the adhesives in the tape that hold it in place.
Start in a corner, it can be tricky to get a good grip
at first.
Progress slowly not to tear the tape, but do not
over heat the unit.
You will tear some of the tape, don't worry to
much about it. It will still hold in place.
