Image preview - the first page of the document
>> Download G3-Lombard-Screw-Guide-oOUEIM2LfonHMS6J documenatation <<
Text preview - extract from the document
www.iFixit.com
G3 Lombard Screw Guide
Heat Shield Upper Case (bottom)
3 Phillips 2 T8 Torx
To organize your screws,
simply place each screw
in the appropriate box
as you remove them
from your laptop.
Modem Upper Case (top)
2 Phillips If you are not planning 4 T8 Torx
on immediately
reassembling your
laptop, you may want to
tape the screws to this
paper.
Due to model variations,
HD Replacement the screws you remove Power Card
4 T8 Torx may differ slightly from 2 T8 Torx
this guide.
Display Framework
4 T8 Torx 2 T8 Torx
Upper Case (top) Framework
5 T8 Torx 1 5mm Standoff
Upper Case (top) PC Card Cage
2 T8 Torx 2 Phillips
Upper Case (bottom) PC Card Cage
5 T8 Torx 2 Phillips
