Installing iPad 3G Display Assembly




                Installing iPad 3G Display Assembly

                                       Step 1 - Display Assembly
                                          The iPad shown in the photos may look
                                          slightly different from your iPad, but the
                                          procedure is the same.

                                          Insert a metal spudger between the right edge of the
                                          display assembly and the rear panel assembly.
                                          Rotate the spudger away from you to release the tabs
                                          along the top edge of the display.




                                       Step 2
                                          Insert a second metal spudger between the top edge of
                                          the display assembly and the rear panel assembly to
                                          keep the tabs from snapping back into place.
                                          Pry the display assembly away from the rear panel.
