Installing iPod Mini Bottom Bezel




                    Installing iPod Mini Bottom Bezel
      Tools used in this guide                   Parts relevant to this guide
           Small Flathead Screwdriver                iPod Mini Bottom Bezel



                                         Step 1 - Bottom Bezel
                                           Carefully insert a small flathead screwdriver in the
                                           seam between the metal casing and white plastic
                                           bottom Use the screwdriver to pry up the white plastic
                                           bottom bezel. Be careful not to damage the soft plastic
                                           with your screwdriver.




                                         Step 2
                                           Use a flathead screwdriver to pry out the metal
                                           retaining bracket beneath the bottom bezel. You can
                                           free the bracket by first pushing in the metal arms on
                                           the corners and then lifting the bracket
