Image preview - the first page of the document
>> Download clarion_pn1632d_e5749_00_audio_car_205 documenatation <<
Text preview - extract from the document
Clarion Co., Ltd. Published by Service Dept.
Export Division - 22-3, Shibuya 2-chome, Shibuyaku, Tokyo, 150-8335 Japan Tel: 03-3400-1121 298-5749-00 May.1999 P
Service Dept.- 50 kamitoda,Toda-shi,Saitama,335-8511 Japan Tel: 048-443-1111 FAX:048-433-6996 Printed in Japan
Service Manual
NISSAN Automobile Genuine
AM/FM Radio Cassette Stereo
Model PN-1632D
(Genuine No. 28111 2Y900)
(ID No. CK586)
SPECIFICATIONS
Radio section General
Tuning system: PLL Frequency synthesizer system Load impedance: 4 4
Receive range: AM 530kHz to 1,710kHz Power output: 15W 4
FM 87.75MHz to 107.9MHz Power supply voltage: DC13.2V(10.8V to 15.6V)
Intermediate frequency: Negative ground
AM 450kHz Consumptive current: Less than 10A(MAX)
FM 10.7MHz Dimensions(mm): 180(W) 52(H) 160(D)
Quieting sensitivity: AM Less than 37dB Weight: 1.3kg
(at 20dB S/N)
FM Less than 15dB Dolby noise reduction manufactured under license from
(at 30dB S/N) Dolby Laboratories Licensing Corporation.
Separation: FM More than 20dB(1kHz) "DOLBY" and the double-D symbol are trademarks of
Auto tuning stop sensitivity: Dolby Laboratories Licensing Corporation.
AM 39 6dB Specifications and design are subject to change without
FM 32 6dB notice for further improvement.
Tape section COMPONENTS
Reproducting system: 4 track 2 program
PN-1632D-A
2 channel stereo system
Main unit 1
Wow and flutter: Less than 0.15 (W.R.M.S)
Separation: More than 35dB
Cross talk: More than 40dB NOTE
S/N ratio: Normal tape(120 s) We cannot supply PWB with component parts in
More than 45dB(DOLBY B NR off) principle.When a circuit on PWB has failure,please re-
More than 55dB(DOLBY B NR on) pair it by component parts base.Parts which are not
Metal tape(70 s) mentioned in service manual are not supplied.
More than 47dB(DOLBY B NR off)
More than 57dB(DOLBY B NR on)
FF/REW time: 110sec.(C-60)
-1- PN-1632D
To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow If extended damage is caused due to negligence of re-
pair, the legal responsibility shall be with the repairing
the instructions so that customers and Engineers
company.
in charge of repair or inspection can avoid suf- 4. Caution in removal and making wiring connection to the
fering any risk or injury. parts for the automobile.
1. Use specified parts. Disconnect the battery terminal after turning the ignition
The system uses parts with special safety features against key off. If wrong wiring connections are made with the
fire and voltage. Use only parts with equivalent charac- battery connected, a short circuit and/or fire may occur.
teristics when replacing them. If extensive damage is caused due to negligence of re-
The use of unspecified parts shall be regarded as re- pair, the legal responsibility shall be with the repairing
modeling for which we shall not be liable. The onus of company.
product liability (PL) shall not be our responsibility in cases 5. Cautions regarding chips.
where an accident or failure is as a result of unspecified Do not reuse removed chips even when no abnormality
parts being used. is observed in their appearance. Always replace them
2. Place the parts and wiring back in their original positions with new ones. (The chip parts include resistors, capaci-
after replacement or re-wiring. tors, diodes, transistors, etc). The negative pole of tanta-
For proper circuit construction, use of insulation tubes, lum capacitors is highly susceptible to heat, so use spe-
bonding,gaps to PWB, etc, is involved. The wiring con- cial care when replacing them and check the operation
nection and routing to the PWB are specially planned afterwards.
using clamps to keep away from heated and high voltage 6. Cautions in handling flexible PWB
parts. Ensure that they are placed back in their original Before working with a soldering iron, make sure that the
positions after repair or inspection. iron tip temperature is around 270 . Take care not to
If extended damage is caused due to negligence during apply the iron tip repeatedly(more than three times)to the
repair, the legal responsibility shall be with the repairing same patterns. Also take care not to apply the tip with
company. force.
3. Check for safety after repair. 7. Turn the unit OFF during disassembly and parts replace-
Check that the screws, parts and wires are put back se- ment. Recheck all work before you apply power to the
curely in their original position after repair. Ensure for unit.
safety reasons there is no possibility of secondary
ploblems around the repaired spots.
BLOCK DIAGRAM
S U B M A IN T U N E R P A C K 8 8 0 -1 9 1 4 E
A M IC 3 0 1
E L E C T R O N IC
A M T U N E R IC 6 0 1
V O L U M E S P E A K E R
F M F E /N C /M P X P O W E R A M P
(V O L /B A S S /T R E B O U T P U T
IC 1 0 1 T A 8 2 5 2 H
B A L /F A D )
F M D IV E R S IT Y L C 7 5 3 8 6
T A 7 3 7 2 P
G F N -1 T A P E M E C H A N IS M
A N T .S IG
IC 4 0 1 B A C K U P
L P F IL L .C O N T
P R E -A M P T U N E R /
P O W E R
D O L B Y C A S S E T T E L IG H T S W
S U P P L Y
A P S C O N R O L A C C
H A 1 2 1 6 3 L C 7 2 3 3 6 O N
S IG N A L
IC 2 0 1
M O T O R -
D R IV E R
T A 7 2 9 1 S
K E Y
L C D
M A T R IX
G N D
C D IN P U T
8 P D IN
PN-1632D -2-
ADJUSTMENTS
Measuring
Item Procedure instrument
FM diver 1. Input the 98.1MHz/55dB (1kHz 30 MOD) signal. SSG
2. Adjust VR104 so that an output of TP101 is 1.0 0.1V. Milli volt meter
Dolby level 1. Insert a Dolby level test tape(400Hz,200nWb/m). Milli volt meter
2. Adjust VR1(L)/VR2(R) so that an output of TP201(L)/TP202(R) is 300mV 1dB.
EXPLANATION OF IC
LC72336-9464 052-1132-10 AM FM Tuner and Tape Controller
/ LCD driver
pin 49 : S 7 : O : Output terminal of internal LCD driver.
1. Outward Form : 80 pins QFP pin 50 : S 6 : O : Output terminal of internal LCD driver.
2. Terminal Description pin 51 : S 5 : O : Output terminal of internal LCD driver.
pin 1 : X IN : IN : Crystal connection. pin 52 : S 4 : O : Output terminal of internal LCD driver.
pin 2 : TEST 2 : - : Not in use. pin 53 : S 3 : O : Output terminal of internal LCD driver.
pin 3 : OPEN : O : Not in use. pin 54 : S 2 : O : Output terminal of internal LCD driver.
pin 4 : VOL MUTE_ : O : Mute signal output to the volume IC. pin 55 : S 1 : O : Output terminal of internal LCD driver.
Negative logic. pin 56 : COM 3 : O : Output terminal of internal LCD driver.
pin 5 : VOL DO : O : Serial data output to the volume IC. pin 57 : COM 2 : O : Output terminal of internal LCD driver.
pin 6 : VOL CL : O : Clock pulse output to the volume IC. pin 58 : COM 1 : O : Output terminal of internal LCD driver.
pin 7 : VOL CE : O : Chip enable signal output to the volume pin 59 : VDD 1 : - : Not in use.
IC. pin 60 : VDD 2 : - : Not in use.
pin 8:P1 : O : Power motor control signal output. pin 61 : AF MUTE_ : O : Audio signal mute signal output.
Ref. Table 1. "L"= Mute ON.
pin 9:P2 : O : Power motor control signal output. pin 62 : COMBI ON_ : O : "L"= Radio ON or Tape ON.
Ref. Table 1. pin 63 : FM ON_ : O : "L"= FM ON.
pin 10 : KO 0 : O : Key scan output terminal. pin 64 : AM ON_ : O : "L"= AM ON.
pin 11 : KO 1 : O : Key scan output terminal. pin 65 : PH 3 : IN : Connect to ground.
pin 12 : KO 2 : O : Key scan output terminal. pin 66 : BIT 1 : IN : Mechanism mode switch signal input.
pin 13 : KO 3 : O : Key scan output terminal. Ref. Table 2.
pin 14 : KO 4 : O : Key scan output terminal. pin 67 : BIT 2 : IN : Mechanism mode switch signal input.
pin 15 : KI 0 : IN : Key scan input terminal. Ref. Table 2.
pin 16 : KI 1 : IN : Key scan input terminal. pin 68 : BIT 3 : IN : Mechanism mode switch signal input.
pin 17 : KI 2 : IN : Key scan input terminal. Ref. Table 2.
pin 18 : KI 3 : IN : Key scan input terminal. pin 69 : HOLD_ : IN : Hold signal input. Negative logic.
pin 19 : TAPE IN : IN : Tape loading start signal input. pin 70 : FM IF : IN : Input terminal of the internal universal
counter for FM IF.
pin 20 : MUSIC SRCH : IN : Music search signal input.
"H"= Non recorded part. pin 71 : AM IF : IN : Input terminal of the internal universal
counter for AM IF.
pin 21 : REEL PULSE : IN : Reel pulse input.
pin 72 : SNS_ : IN : Connect to ground.
pin 22 : EJECT_ : IN : Eject switch input. "L"= Eject.
pin 73 : VDD : - : Positive supply voltage.
pin 23 : M MOTOR : O : "H"= Main motor ON.
pin 74 : FM OSC : IN : Input terminal of the internal universal
pin 24 : RADIO ON : O : Radio ON flag output. counter for FM local OSC.
pin 25 : LCD ON_ : O : LCD back light ON signal output. pin 75 : AM OSC : IN : Input terminal of the internal universal
"L"= ON. counter for AM local OSC.
pin 26 : BEEP : O : Beep signal output. pin 76 : VSS : - : Ground.
pin 27 : SEARCH SNS : O : Sensitivity select signal output to APC pin 77 : EO 1 : O : Error output.
circuit.
pin 78 : EO 2 : - : Not in use.
pin 28 : HEAD SW : O : "H"= Forward, "L"= Reverse.
pin 79 : TEST 1 : - : Not in use.
pin 29 : MECH MUTE : O : Mechanism Mute signal output.
pin 80 : X OUT : O : Crystal connection.
pin 30 : DOLBY ON : O : Dolby ON signal output.
pin 31 : VDD : - : Positive supply voltage.
pin 32 : TWT_/ST_/SD : I/O : AM mode : Table 1. Power motor control signal output
Tweet signal output.
"L"= 900kHz received. Mechanism Mode P1 (pin8) P2 (pin9)
FM mode : Loading head shift forward H L
Stereo detection signal input. Eject head go back L H
"L"= Stereo.
Keep H H
AM/FM seek mode :
Station detection signal input. Stop L L
pin 33 : RF MUTE : O : RF mute signal output.
pin 34 : DX /LO_ : O : Not in use.
Table 2. Mechanism mode switch signal input
pin 35 : Power on off_ : IN : Power switch input. Negative logic.
pin 36 : VOL 1 : IN : Volume switch input. bit 1 bit 2 bit 3
Mechanism Mode ( pin66 ) ( pin67 ) ( pin68 )
pin 37 : VOL 2 : IN : Volume switch input.
Eject H H H
pin 38 : SYSTEM ON : O : Power supply circuit control signal output.
pin 39 : AMP ON : O : Audio power amplifier ON signal output. Loading H H L
pin 40 : S 16 : O : Output terminal of internal LCD driver. Stop L H L
pin 41 : S 15 : O : Output terminal of internal LCD driver. FWD FF ( REV REW ) L L H
pin 42 : S 14 : O : Output terminal of internal LCD driver. FWD REW ( REV FF ) H L L
pin 43 : S 13 : O : Output terminal of internal LCD driver. FWD Play H L H
pin 44 : S 12 : O : Output terminal of internal LCD driver. REV Play L H H
pin 45 : S 11 : O : Output terminal of internal LCD driver.
pin 46 : S 10 : O : Output terminal of internal LCD driver.
pin 47 : S 9 : O : Output terminal of internal LCD driver.
pin 48 : S 8 : O : Output terminal of internal LCD driver.
-3- PN-1632D
EXPLODED VIEW PARTS LIST
3 9
3 9
3 9
3 5
3 6
3 9
3 0
3 8
3 7
3 8 3 3
3 8
2 9
3 1 3 2
3 2
3 3
3 3
2 4
3 8
2 3
2 2
1 2
1 1 2 8
1 3 2 7
2 6
1 0
2 5 2 1
2 4 0
1 9 2 0
6
1 5 3 9
4 3 9
3 9
3
3 9 3 4 3 9
9
8
7
1 8 5
1 7
1 4
1 6
1 5
PN-1632D -4-
NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY
1 940-7756-00 ESCUTCHEON-ASSY 1 21 880-1914E TUNER(AM/FM) 1
2 016-0010-04 VARIABLE RESISTOR 1 22 074-0850-08 OUTLET SOCKET(DIN8P) 1
3 013-3934-02 SWITCH 14 23 074-1141-00 OUTLET SOCKET 1
4 017-0420-22 PILOTLAMP(14V40mA) 4 24 051-2030-00 IC(TA8252H) 1
5 039-1417-00 SWITCH PWB 1 25 076-0477-16 PLUG(16P) 1
(WITHOUT COMPONENT)
26 076-0461-20 PLUG(20P) 1
6 074-1047-16 OUTLET SOCKET(16P) 1
27 345-8023-00 SPACER 1
7 074-1012-03 OUTLET SOCKET(3P) 1
28 331-2475-00 REAR PLATE 1
8 345-4157-76 LAMP CAP 1
29 313-1741-00 HEAT SINK 1
9 017-0369-01 PILOTLAMP(8V150mA) 1
30 331-2471-00 MECH-BRKT 1
10 380-5317-01 KNOB 1
31 309-0710-01 FRONT PLATE 1
11 320-0529-75 DUSTPROOF-CVR 1
32 714-2610-81 MACHINE SCREW(M2.6 10) 2
12 750-2626-00 SPRING 1
33 714-2606-81 MACHINE SCREW(M2.6 6) 3
13 716-0872-00 PAD SCREW(M1.7 5) 6
34 948-0531-01 LOWER CASE ASSY 1
14 335-5121-00 LAMP HOUSE 1
35 310-1663-00 UPPER CASE 1
15 331-1925-01 LCD COVER 1
36 286-9233-00 SETPLATE 1
16 379-1138-30 INDICATOR(LCD) 1
37 930-0790-02 TAPE-MECHANISM 1
17 335-5213-00 COLOR FILTER 1
38 714-2606-81 MACHINE SCREW(M2.6 6) 4
18 335-5120-00 LCD HOLDER 1
39 716-1494-00 IT SCREW(M2.6 6) 9
19 076-0454-03 PLUG(3P) 1
40 800-0206-00 VINYL-COAT-WIRE(BLK) 2
20 039-1350-00 MAIN PWB 1
(WITHOUT COMPONENT)
-5- PN-1632D
Tape mechanism section
3 9
1 1 1 5
J
4 7 1 1 -1
5 4
3 9
X 4 0
L
1 7 3 6
1 6
5 1 K
2 4
1 6 -1
I'
1 6 -2 1 6 -3
W
3 7 1 6 -4
5 0
2 2
3 9
E
I
3 9 4 6 7 O
3 5 M
X M
3 9 3 9
1 9
F O '
3 4 3 9 3 9
L O 8
2 8
1 8
5 2 O ' 3 2 2 3
A N
4 5
1 4 3 3
5 3 4 4 1
N ' 2
2 9
J Q
P E I'
A
2 6 R 4 4
P
3 0 Y ' F 4 3 4 9
G 1 3 8
N
K
Q I 4 8
C
G '
5 N '
D '
Q ' 3 1
H B 9
Z
R Y D
2 6 Q ' C ' C G
H '
1 0
Y ''' 3
H ' Y ''
4 3 G '
C '
H
1 3
4 3
Y ''
Y ' W 2 7 4 2
Y
D
Z 2 0
6 1 2 -2 4 3 B
1 2 -3 D '
2 1
1 2 -6 Y '''
1 2 -5
1 2 -4 4 3
1 2 -1
1 2 2 5
3 9
PN-1632D -6-
NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY
1 960-4294-14 DECK PLATE ASSY 1 22 606-0101-08 PACK GUIDE 1
2 960-4261-05 HEAD PLATE ASSY 1 23 610-0342-01 HEAD-P-ROLLER 1
3 960-4262-03 FF/REW-P-ASSY 1 24 610-0343-00 GUIDE-A-ROLLER 1
4 960-4263-03 IDLER-P-ASSY L 1 25 611-0091-02 FLYWHEEL 2
5 960-4264-03 IDLER-P-ASSY R 1 26 613-0662-00 IDLER GEAR 2
6 960-4266-05 MODE PLATE ASSY 1 27 613-0286-02 FF/REW GEAR 2
7 960-4269-05 ROLLER ASSY F 1 28 613-0288-01 HELICAL GEAR 1
8 960-4270-05 ROLLER ASSY R 1 29 613-0289-01 GEAR A 1
9 960-4348-03 REEL ASSY F 1 30 613-0337-00 POWER GEAR 1
10 960-4349-03 REEL ASSY R 1 31 630-2597-01 CHANGE LINK 1
11 960-4298-09 EJECT SUB ASSY 1 32 630-2598-05 EJECT LINK 1
11-1 750-2948-01 SWITCH PLATE SPRING 1 33 630-2600-01 ADJUST LINK 1
12 960-4338-07 BOTTOM SUB ASSY 1 34 630-2601-02 MOTOR PLATE 1
12-1 960-4295-02 BOTTOM-P-ASSY 1 35 630-2626-05 PWB FRAME 1
12-2 099-9926-01 FLEXIBLE PWB 1 36 630-2605-02 GUIDE ARM 1
(WITHOUT COMPONENT)
37 631-1992-02 PACK STOPPER 1
12-3 013-3951-11 SWITCH(MODE) 1
38 631-1993-01 SLIDE BUSH 2
12-4 013-3953-01 SWITCH(METAL) 1
39 716-0484-00 SCREW(M2 2.5) 13
12-5 051-1776-00 IC 1
40 716-1676-00 PWB SCREW(M2.6 6) 2
12-6 746-0767-00 WASHER 2
41 716-0833-10 SCREW(M2 5.6) 2
13 960-4282-06 DETECT SUB ASSY 1
42 746-0624-00 WASHER 2
14 960-4301-02 PLAY LINK ASSY 1
43 746-0724-00 WASHER 6
15 039-1436-00 SIDE PWB 1
(WITHOUT COMPONENT) 44 746-0761-00 WASHER 2
16 990-0713-00 REAR PWB ASSY 1 45 746-0762-00 WASHER 1
(WITH COMPONENT)
46 750-2946-02 PINCH SPRING 1
16-1 013-3906-00 SWITCH(TAPE IN) 1
47 750-2947-03 EJECT-P-SPRING 1
16-2 074-1104-20 OUTLET SOCKET(20P) 1
48 750-2949-00 SLIDE SPRING 2
16-3 076-0368-10 PLUG(10P) 1
49 750-3017-02 IDLER-P-SPRING 1
16-4 039-0489-00 REAR PWB 1
50 800-4910-60 WIRE(BLK) 1
17 SMA-130-100 MAIN MOTOR ASSY 1
51 802-4911-60 WIRE(RED) 1
18 SMA-131-100 POWER MOTOR ASSY 1
52 806-4914-60 WIRE(BLU) 1
19 011-0307-34 HEAD 1
53 809-4914-60 WIRE(WHT) 1
20 602-0118-00 BELT 1
54 074-0898-10 OUTLET SOCKET(10P) 1
21 604-0046-00 TENSION PULLEY 1
-7- PN-1632D
ELECTRICAL PARTS LIST
Note) Several different parts of the same reference number are alternative parts.
Main PWB section(B1) One of those parts is used in the set.
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C101 176-6801-00 68pF CH C403 176-1007-00 10pF CH D401 001-0517-00 1SS355
C102 178-1042-78 0.1 F C405 176-1501-00 15pF CH D702 001-0626-00 1A2
C103 176-6801-00 68pF CH C406 176-1201-00 12pF CH D702 001-0466-00 S5688B
C104 178-1042-78 0.1 F C407 176-1011-00 100pF CH D703 001-0334-30 RL202
C105 183-1063-32 16V10 F C409 178-1032-78 0.01 F D704 001-0626-00 1A2
C106 183-1053-62 50V1 F C410 178-1022-78 1000pF D704 001-0466-00 S5688B
C107 183-6843-62 50V0.68 F C412 176-1011-00 100pF CH D801 001-0377-34 MA4062L
C108 176-1511-00 150pF CH C413 176-4096-00 4pF CH D801 001-0376-34 MTZJ6.2A
C109 176-2701-00 27pF CH C414 176-1011-00 100pF CH D801 001-0400-34 HZS6.2JB1
C110 176-2701-00 27pF CH C415 178-1042-78 0.1 F D901 001-0377-41 MA4075M
C111 176-1007-00 10pF CH C416 178-1042-78 0.1 F D901 001-0376-42 MTZJ7.5C
C114 183-1063-32 16V10 F C417 178-1022-78 1000pF D901 001-0400-41 HZS7.5JB2
C115 183-1073-22 10V100 F C418 176-1011-00 100pF CH D902 001-0377-37 MA4068L
C116 173-1021-11 1000pF J C419 178-1022-78 1000pF D902 001-0376-38 MTZJ6.8B
C117 042-0458-00 50V1 F C501 183-1063-32 16V10 F D902 001-0400-37 HZS6.8JB1
C118 178-3932-78 0.039 F C502 183-1063-32 16V10 F D903 001-0377-48 MA4091H
C119 183-4763-32 16V47 F C503 183-1063-32 16V10 F D903 001-0376-49 MTZJ10A
C120 178-3932-78 0.039 F C504 183-1063-32 16V10 F D903 001-0400-48 HZS9.1JB3
C121 178-1042-78 0.1 F C601 178-1032-78 0.01 F D904 001-0516-00 MA111
C124 183-1056-61 50V1 F NP C602 178-2232-78 0.022 F D904 001-0517-00 1SS355
C125 042-0427-02 16V33 F C603 178-1032-78 0.01 F D905 001-0376-31 MTZJ5.6A
C146 183-1053-62 50V1 F C604 172-1041-11 0.1 F D905 001-0400-31 HZS5.6JB1
C147 178-1532-78 0.015 F C605 172-1041-11 0.1 F D906 001-0516-00 MA111
C149 178-2232-78 0.022 F C606 172-1041-11 0.1 F D906 001-0517-00 1SS355
C150 183-1073-22 10V100 F C607 172-1041-11 0.1 F IC101 051-1282-00 TA7372P
C151 178-1022-78 1000pF C608 183-1063-32 16V10 F IC201 051-1014-10 TA7291S
C152 178-1032-78 0.01 F C609 183-1053-62 50V1 F IC301 051-5012-00 LC75386
C160 178-1032-78 0.01 F C610 183-1063-32 16V10 F IC401 052-1132-10 LC72336-9464
C161 176-1011-00 100pF CH C702 178-2222-78 2200pF IC601 051-2030-00 TA8252H
C162 178-1032-78 0.01 F C703 172-1041-11 0.1 F J201 076-0461-20 20P
C163 176-4711-00 470pF CH C704 178-2222-78 2200pF J501 074-0850-08 8P
C164 178-1022-78 1000pF C705 178-2222-78 2200pF J701 074-1141-00 NS10+6
C165 176-1011-00 100pF CH C707 178-2222-78 2200pF L101 010-2330-63 2.7 H
C166 176-1011-00 100pF CH C708 178-2222-78 2200pF L102 010-2003-04 COIL
C167 178-1022-78 1000pF C709 042-0571-00 16V2200 F L103 010-2330-24 22 H J
C174 176-1007-00 10pF CH C710 178-2222-78 2200pF L104 010-2330-24 22 H J
C175 176-1011-00 100pF CH C711 178-2222-78 2200pF L106 010-2330-20 10 H J
C201 178-1042-78 0.1 F C712 178-2222-78 2200pF L108 010-2330-24 22 H J
C202 178-1042-78 0.1 F C713 178-2222-78 2200pF L110 010-2198-53 5.6 H
C205 042-0452-02 16V100 F C714 183-1063-32 16V10 F L401 010-2198-61 0.12 H
C206 042-0452-02 16V100 F C715 178-1042-78 0.1 F L701 009-0670-01 CHOKE
C210 178-2255-79 2.2 F C720 178-1042-78 0.1 F L901 010-2330-12 2.2 H J
C211 178-2255-79 2.2 F C721 178-1042-78 0.1 F P401 076-0477-16 PLUG
C212 178-1022-78 1000pF C722 178-1042-78 0.1 F P901 076-0454-03 3P
C213 178-1022-78 1000pF C723 178-1042-78 0.1 F Q101 102-2712-00 2SC2712
C301 183-1063-32 16V10 F C801 183-1053-62 50V1 F Q101 102-2412-00 2SC2412
C302 172-1041-11 0.1 F C901 178-1042-78 0.1 F Q101 103-0601-00 2SD601
C303 172-1041-11 0.1 F C902 178-1042-78 0.1 F Q102 125-9012-90 IMD6A
C304 183-1063-32 16V10 F C903 183-4756-51◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
