Image preview - the first page of the document
PAPAMY1501054CE


>> Download PAPAMY1501054CE documenatation <<

Text preview - extract from the document
                                                                                                             Order No: PAPAMY1501054CE




                                                                              Indoor Unit                        Outdoor Unit
                                                                             CS-PE9RKE                            CU-PE9RKE
      (PE9/12RKE)
                                                                            CS-PE12RKE                           CU-PE12RKE
                                                                             CS-UE9RKE                            CU-UE9RKE
                                                                            CS-UE12RKE                           CU-UE12RKE
                                                                            CS-UE18RKE                           CU-UE18RKE
      (UE9/12RKE)

                                                                                                                      Destination
                                                                                                                          Europe
      (UE18RKE)
                                                                                                                        E.Europe
                                                                                                                          Turkey




                                                              WARNING
   This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
    Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
      service or repair the products dealt with in this service information by anyone else could result in serious injury or death.




                                              PRECAUTION OF LOW TEMPERATURE
      In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
