Image preview - the first page of the document



>> Download TD831170-B11CE documenatation <<

Text preview - extract from the document

                                                                                                                                           Order No. TD831170-11CE




Model No.
Outdoor Unit
             Class            8HP         10HP        12HP        14HP        16HP

MF2     Model Name          U-8MF2E8    U-10MF2E8   U-12MF2E8   U-14MF2E8   U-16MF2E8


Indoor Unit
             Class              15          22          28          36          45          56          60          73          90          106          140        160
U1 4-Way Cassette                       S-22MU1E51 S-28MU1E51 S-36MU1E51 S-45MU1E51 S-56MU1E51 S-60MU1E51       S-73MU1E51   S-90MU1E51 S-106MU1E51 S-140MU1E51 S-160MU1E51
                                        S-22MU1E5 S-28MU1E5 S-36MU1E5 S-45MU1E5 S-56MU1E5                       S-73MU1E5               S-106MU1E5 S-140MU1E5 S-160MU1E5
Y1 4-Way Cassette 60
