Image preview - the first page of the document
SBPAC1612014CE


>> Download SBPAC1612014CE documenatation <<

Text preview - extract from the document
Order No. SBPAC1612014CE




                      C
                                        Contents


System Configuration ...................................................................A-1

Outdoor Unit .................................................................................B-1

Control-Related ............................................................................C-1

System Design .............................................................................D-1

Installation Work ...........................................................................E-1

Separately Sold Parts ..................................................................F-1

Periodic Inspection .......................................................................G-1
System Configuration

                                                          Contents
   1. Type Configuration
      (1) Outdoor unit ............................................................................................................ A-2




                                                                   A-1
System Configuration                                   1. Type Configuration

(1) Outdoor Unit

   2WAY W Multi (16, 20, 25 and 30 Horsepower)
   3WAY Multi (16, 20 and 25 Horsepower)




                                           U-16GE3E5
                                           U-20GE3E5
                                           U-25GE3E5
                                           U-30GE3E5
                                           U-16GF3E5
                                           U-20GF3E5
                                           U-25GF3E5




                                                 A-2
Outdoor Unit

                                                           Contents
   1. Gas Usage Conditions
        (1) Usable Gas ............................................................................................................. B-2
        (2) Gas Supply Pressure .............................................................................................. B-2
        (3) Applicable Gas Type................................................................................................ B-2
        (4) Gas Maximum Flow Volume .................................................................................... B-2
        (5) When using Propane .............................................................................................. B-3

   2. Specifications......................................................................................................B-4

   3. External Dimensions...........................................................................................B-11

   4. Wiring Diagram ...................................................................................................B-15

   5. Performance Characteristics...............................................................................B-16

   6. Vibration Force
        (1) Measurement Points ............................................................................................... B-36
        (2) Vibration Force ........................................................................................................ B-36




                                                                    B-1
Outdoor Unit                                                                 1. Gas Usage Conditions

(1) Usable Gas

   Depending upon the calorific value of the natural gas, the setting for the gas fuel flow rate adjustment
   nozzle will differ.
   * If the gas type changes due to relocation or fuel conversion, gas type setting is required.


(2) Gas Supply Pressure
                                                                                                        Units: mbar
             Gas Type                    Maximum                    Standard                 Minimum
                   P                          45                       37                          25
              H, L, E                         25                       20                          17



(3) Applicable Gas Type

              Group                       P                  H                  L                       E
        Gas composition
                                     C3H8 100%           CH4 100%        CH4 86% N2 14%            CH4 100%
         Standard gas
                                        G31                G20                 G25                   G20
         Calorific value
                                       95.65              37.78               32.49                 37.78
           (MJ/m3N)
               45.0 kW Type
     Model     56.0 kW Type
     Name      71.0 kW Type
               85.0 kW Type

   Applicability        : Standard setting when shipped from the factory
                        : Necessary to change the gas type setting on site


(4) Gas Maximum Flow Volume

                                    Gas Maximum Flow
       Outdoor unit type
                                      Volume (kW)
             45.0 kW                          57
             56.0 kW                          69
             71.0 kW                          80
             85.0 kW                          90

   The gas maximum flow volume is the quantity of gas consumed after start up and operating at full capacity,
   with the gas at 40
