Image preview - the first page of the document



>> Download scf_p documenatation <<

Text preview - extract from the document

                                                                                 Scart P.C.B.(Foil Side)
                           Integrated Circuit    Coil              C3934   C-8    Resistor              R3916       B-3   R3935   C-4   R3983      B-6
                           IC3901     B-8        LB3907      B-6   C3938   C-8    R3901     B-1         R3917       B-3   R3962   C-3   R3984      B-6
                           Transistor            LB3908      B-5   C3939   C-8    R3902     C-2         R3919       D-8   R3967   B-3   R3985      D-9
                           Q3901      B-2        LB3911      C-5   C3951   B-5    R3903     C-2         R3921       B-4   R3968   B-3   R3986      D-8
                           Q3905      B-3        LB3912      C-6   C3952   B-5    R3904     C-9         R3922       B-6   R3969   B-3   R3987      A-5
                           Q3906      B-3        LB3913      C-6   C3953   A-5    R3905     B-2         R3923       B-6   R3972   C-9   R3988      A-6
                           Q3908      B-6        LB3922      B-1   C3954   A-6    R3906     B-2         R3925       B-5   R3973   C-9   R3989      A-5
                           Q3909      B-6        LB3923      C-2   C3955   B-5    R3907     B-2         R3926       B-5   R3975   C-7   R3990      A-5
                           Q3910      B-6        LB3925      D-8   C3956   B-6    R3908     B-9         R3927       B-4   R3976   C-8   R3991      C-5
                           Transistor-resistor   Capacitor         C3957   C-6    R3909     B-9         R3928       B-3   R3977   A-6   R3992      C-6
                           QR3908 B-3            C3920       B-8   C3958   C-6    R3910     D-9         R3929       C-6   R3978   A-6   R3993      C-6
                           QR3909 A-6            C3922       B-4   C3959   C-5    R3911     C-8         R3930       C-6   R3979   B-7   R3994      C-5
                           QR3913 B-3            C3923       B-7   C3960   C-5    R3912     C-8         R3932       C-5   R3980   B-7
                           Diode                 C3925       C-4   C3961   C-5    R3914     D-8         R3933       C-3   R3981   B-6
                           D3903      B-6        C3930       C-8   C3962   C-6    R3915     B-3         R3934       C-4   R3982   B-6



    Scart P.C.B.
D




C




B




A


                                                                                                                                          DMR-E95HEB/EG
    (FOIL SIDE)                                                                                                                           Scart P.C.B. (Foil Side)
                                                                                                                                          (REP3682A)
       1           2   3                         4                   5                 6                        7                  8                     9
