Image preview - the first page of the document

>> Download SA-AK240GCP.part2 documenatation <<

Text preview - extract from the document
                                                                                                          ORDER NO. MD0512480C3

                                                                                                CD Stereo System
                                                                (S)... Silver Type

  Notes: This model's CD mechanism changer unit is CRS1. Please refer to the original Service Manual
  (Order No. MD0509368C0) for this mechanism.

n AMPLIFIER SECTION                                             Mic jack
RMS output power                                                Terminal                                           Mono, 3.5 mm jack
THD 10%, both channels driven                                   Sensitivity                                             0.7 mV, 680
1 kHz                                115 W per channel (3 )     n CASSETTE DECK SECTION
Total output power                                    230 W     Track system                                        4 track, 2 channel
n FM/AM TUNER, TERMINALS SECTION                                Heads
Preset station                                 FM 15 stations   Record/playback                                  Solid permalloy head
                                              AM 15 stations    Erasure                                        Double gap ferrite head
Frequency Modulation (FM)                                       Motor                                                  DC servo motor
Frequency range                  87.50 to 108.00 MHz (50 kHz    Recording system                                     AC bias 100 kHz
                                                       steps)   Erasing system                                      AC erase 100 kHz
Sensitivity                                      4.0
