Image preview - the first page of the document
>> Download PANASONIC_SA-AK240GCP_sm documenatation <<
Text preview - extract from the document
ORDER NO. MD0512480C3
CD Stereo System
SA-AK240GCP
Colour
(S)... Silver Type
Notes: This model's CD mechanism changer unit is CRS1. Please refer to the original Service Manual
(Order No. MD0509368C0) for this mechanism.
Specifications
n AMPLIFIER SECTION Mic jack
RMS output power Terminal Mono, 3.5 mm jack
THD 10%, both channels driven Sensitivity 0.7 mV, 680
1 kHz 115 W per channel (3 ) n CASSETTE DECK SECTION
Total output power 230 W Track system 4 track, 2 channel
n FM/AM TUNER, TERMINALS SECTION Heads
Preset station FM 15 stations Record/playback Solid permalloy head
AM 15 stations Erasure Double gap ferrite head
Frequency Modulation (FM) Motor DC servo motor
Frequency range 87.50 to 108.00 MHz (50 kHz Recording system AC bias 100 kHz
steps) Erasing system AC erase 100 kHz
Sensitivity 4.0 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
