Image preview - the first page of the document
sa ak25


>> Download sa ak25 documenatation <<

Text preview - extract from the document
TechInfo Sheet                                                                       fax: 01344 853689

Audio Visual                                                   email:av.technical@mail.panasonic.co.uk

Product Group: Hi-Fi Audio                       Model: CR20 (CD Changer mechanism)
Date: 17/01/00                              Revision No: 1.0            Document No: 01
Subject: Disc spacer comes off


Symptom:      The Disc spacer coming off affects other mechanical operations.
              The following symptoms will appear.
              * CD Changer operation does not work.
              * CD does not play.
              * CD tray does not open.

Cause:        This mechanism controls the switching of Disc Up/Down and Tray Open/Close operation
              using the Change gear. (Refer to following diagrams)
              If the Change gear does not drop down due to tight engaging between the Change gear and
              Drive gear when switching to Tray open/close operation, the disc spacer will come off.




  Panasonic CS U.K.                                                             Document No: 01
                                                                                Model: SA-AK27
                                                      1
TechInfo Sheet                                                                   fax: 01344 853689

Audio Visual                                                 email:av.technical@mail.panasonic.co.uk




Remedy: Replace the Change gear spring to a stronger one .




Action on production: From October 1999 onwards




  Panasonic CS U.K.                                                         Document No: 01
                                                                            Model: SA-AK27
                                                      2
