Image preview - the first page of the document



>> Download PSG1107005CE_PRINTDB documenatation <<

Text preview - extract from the document

                                                                                                                                    PSG1107005CE




                                                                                                           CD Stereo System
                                                                           Model No. SA-PM500DBEB
                                                                           Product Color: (K)...Black Type




Notes: Please refer to the Original Service Manual for :
  CD Mechanism Unit (BRS1C), Order No. PSG1102001CE
  Speaker system SB-PM500EG-K/S, Order No. PSG1106006CE




TABLE OF CONTENTS
                                                                 PAGE                                                                          PAGE
 1 Safety Precautions----------------------------------------------- 3          1.6. Safety Part Information -----------------------------------5
    1.1. General Guidelines---------------------------------------- 3        2 Warning --------------------------------------------------------------6
    1.2. Caution for AC Cord -------------------------------------- 4           2.1. Prevention of Electro Static Discharge (ESD)
    1.3. Before Repair and Adjustment ------------------------- 5                    to Electrostatically Sensitive (ES) Devices ----------6
    1.4. Caution For Fuse Replacement------------------------ 5                 2.2. Precaution of Laser Diode -------------------------------7
    1.5. Protection Circuitry ---------------------------------------- 5        2.3. Service caution based on Legal restrictions --------8
