Image preview - the first page of the document
c9dpm


>> Download c9dpm documenatation <<

Text preview - extract from the document
Commercial discs
                                            Indicated in these
     Disc                Logo                                                                         Remarks
                                              instructions by

  DVD-Video                                          DVD-V                       High quality movie and music discs


                                                     VCD                         Music discs with video
   Video CD
                                                                                 Including SVCD (Conforming to IEC62107)

      CD                                               CD                        Music discs

Recorded discs ( : Playable,       : Not playable)
                                                Recorded on a
                                                                                     Recorded on a personal
                                                  DVD video                                                                        6
       Disc                 Logo                                                         computer, etc.               Finalizing
                                                recorder, etc.

                                              DVD-VR       2   DVD-V       4   WMA     MP3     JPEG   MPEG4   DivX



    DVD-RAM                                                      --            --                                     Not necessary




    DVD-R/RW                                                                   --                                      Necessary




    DVD-R DL                                           3
                                                                               --      --      --      --       --     Necessary



    + R/+ RW
        +                     --                --             ( )     5
                                                                               --      --      --      --       --     Necessary
      + R DL                  --                --             ( )     5
                                                                               --      --      --      --       --     Necessary
    CD-R/RW    1
                              --                --              --                                                     Necessary   7



* For EG only
   It may not be possible to play all the above-mentioned discs in some cases due to the type of disc, the condition of
  the recording, the recording method, or how the files were created. [ Refer to Section 7.7.2. File Extension Type Support
  1
                                                                                              WMA/MP3/JPEG/MPEG4/DIVX)]
    This unit can play CD-R/RW recorded with CD-DA or Video CD format.
 2
    Discs recorded on DVD recorders or DVD video cameras, etc. using Version 1.1 of the Video Recording Format (a
    unified video recording standard).
  3
    Discs recorded on DVD recorders or DVD video cameras using Version 1.2 of the Video Recording Format (a
    unified video recording standard).
  4
    Discs recorded on DVD recorders or DVD video cameras using DVD-Video Format.
 5
    Recorded using a format different from DVD-Video Format, therefore some functions cannot be used.
  6
    A process that allows play on compatible equipment. To play a disc that is indicated as "Necessary", the disc must
    first be finalized on the device it was recorded on.
  7
    Closing the session will also work.
Note about using a DualDisc
The digital audio content side of a DualDisc does not meet the technical specifications of the Compact Disc Digital Audio
(CD-DA) format so playback may not be possible.
  Discs that cannot be played                                                       Video systems
    Blu-ray, HD DVD, AVCHD discs, DVD-RW version                                     This unit can play PAL and NTSC, but your TV must
    1.0, DVD-Audio, DVD-ROM, CD-ROM, CDV, CD-G,                                      match the system used on the disc.
    SACD, DivX Video Discs and Photo CD, DVD-RAM                                     PAL discs cannot be correctly viewed on an NTSC
    that cannot be removed from their cartridge, 2.6 GB                              TV.
    and 5.2 GB DVD-RAM, and "Chaoji VCD" available                                   This unit can convert NTSC signals to PAL 60 for
                                                                                     viewing on a PAL TV (OI 22, "NTSC DISC OUT" in
    on the market including CVD, DVCD and SVCD that
                                                                                     "VIDEO" menu).
    do not conform to IEC62107.
